Side 1/9
MA-37 Multi-pattern Vacuum Tube
Condenser Microphone
Please visit www.mojaveaudio.com for more information including:
• Recording Tips
• FAQ’s
• Warranty Registration
• Customer Service
CONTENTS
CONTENTS 1
INTRODUCTION 2
UNPACKING AND INSPECTION 2
GENERAL INFORMATION 3
SAFETY INSTRUCTIONS 3
OPERATION 4
CARE OF YOUR MICROPHONE 5
TECHNICAL SPECIFICATIONS 6
POLAR RESPONSE 7
POLAR PATTERN SELECTOR 8
BASS CUT SWITCH 8
WARRANTY 9
INTRODUCTION
Congratulations on your purchase of a Mojave Audio MA-37 Multi-pattern Vacuum Tube
Condenser Microphone. Your MA-37 was carefully designed and constructed using only the
finest materials. The MA-37 microphone capable of delivering superb performance and, is
with minimal care, will do so for many years. Your MA-37 was thoroughly tested and given a
24-hour factory burn in prior to shipment.
The MA-37’s capacitor capsule and electronics are adapted from mid-1950’s design practice. The
MA-37 utilizes a European-made EF-86 vacuum tube and a Lundahl audio output transformer
wound to our specifications. By utilizing modern components, the microphone system emulates
the performance of “classic” tube microphones without using esoteric, unreliable, or hard to find
components.
The MA-37 is guaranteed to perform as specified and is suitable for recording even the most
demanding music, provided that the microphone is used sensibly.
For optimum performance from your microphone, please read this manual thoroughly and
familiarize yourself with the proper use of the MA-37.
UNPACKING AND INSPECTION
Carefully unpack your MA-37 and verify that of the accessories included the all with
microphone are accounted for. Do not discard any packing materials! If anything is missing or
damaged, contact your dealer or Mojave Audio immediately.
Items included the MA-37 are:with
1. MA-37 microphone inside a pelican-style carrying case.
2. operated microphone power supply.AC
3. 20-foot premium microphone cable 5-pin and female connectors.with male
4. power cable for power supply - molded IEC business machine type AC with plug.
5. Rugged carrying for above case all items.
Verify that the serial number of your MA-37 matches correctly with the one on your receipt. The
MA-37 serial number can be found on the silver ring found just above the base. When
corresponding with Mojave Audio about your microphone or when service is required, we will
need know the serial number, so keep handy. to it
GENERAL INFORMATION
The MA-37 is a multi-pattern vacuum tube microphone and requires a dedicated power supply
and 5-pin cable set for operation. These items are provided with the microphone. The capsule is a
6-micron, single-membrane gold-sputtered type. The vacuum tube head-amplifier delivers wide
bandwidth and low noise operation. The MA-37 utilizes a sub-miniature vacuum tube, which
necessitates the need for a dedicated power supply. The vacuum tube is premium grade EF-86
and will deliver excellent performance for many years. A specially designed, high-quality,
custom wound Lundahl audio output transformer delivers an isolated, truly balanced output
signal, minimizing the possibility of unwanted noise entering the preamplifier. As with all
vacuum tube microphones, a warm-up period is advised for optimum performance; usually about
ten minutes. The MA-37 includes a bass cut switch. selectable
SAFETY INSTRUCTIONS
WARNING!
To avoid electrical shock to yourself and damage to the MA-37, use proper circuit protection.
MA-37s purchased in the USA are set for 120V, 60 Hz operation. MA-37s purchased outside of
the USA are set for the voltages of the country to which they are exported. This information is
duly noted on the outside of the shipping box as well as on voltage selector of the power supply.
The MA-37 uses a line fuse for protection. Never replace this fuse with one of a higher current
rating. only that type which supplied the unit. The power supply cord that is Use was with
supplied with your MA-37 is a standard “business machine” type. It is a good practice to
examine the power cord regularly. Never use a cord that shows damage or that has exposed
wires.
Other than the EF-86 tube, there are no user serviceable components inside the MA-37
microphone or its power supply. Always refer service to a qualified technician equipped to
service this equipment. Never expose the MA-37 microphone, its power supply or cable set to
water or any environment that may create an electrical hazard. In the event of a malfunction,
disconnect the MA-37 immediately and determine the nature of the malfunction before
attempting to use it again.
To avoid tripping over the microphone cable, make certain that the cable is not in the way of
foot traffic, or suspended in an unsafe manner. Make sure that the microphone stand is secure and
not likely to fall.
If you have any questions or concerns about operation of your MA-37 please contact the factory:
info@mojaveaudio.com
