HDMI/HDBT 1x4 Splitter

Installation & Operation Manual

500424

HDMI/HDBT 1x4 Splitter Installation & Operation Manual

SAFETY PRECAUTIONS

To insure the best from the product, please read all instructions carefully before using

the device. Save this manual for further reference.

 Follow basic safety precautions to reduce the risk of re, electrical shock and injury

to persons.

 Do not dismantle the housing or modify the module. It may result in electrical shock

or burn.

 To prevent re or shock hazard, do not expose the unit to rain, moisture or install

this product near water. Keep the product away from liquids.

 Spillage into the housing may result in re, electrical shock, or equipment damage.

If an object or liquid falls or spills on to the housing, unplug the module immediately.

 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to

the device before cleaning.

 Using supplies or parts not meeting the product’s specifications may cause damage,

deterioration or malfunction.

 Refer all servicing to qualied service personnel.

 Install the device in a place with good ventilation to avoid damage due to

overheating.

 Unplug the power cord when left unused for a long period of time.

 Do not put any heavy items on the unit or on extension cable.

 Do not remove the housing of the device as you may be exposed to dangerous

voltage or other hazards.

 Information on disposal devices: do not burn or mix with general household of

waste, please treat them as normal electrical wastes.

 Unpack the equipment carefully and save the original box and packing material for

possible future shipment.

 Please read this user manual carefully before using this product.

HDMI/HDBT 1x4 Splitter Installation & Operation Manual

Contents

Introduction ............................................................................................................... 4 1.

1.1. Introduction to the HDMI/HDBT 1x4 Splitter 4 ..................................................

1.2. Features ......................................................................................................... 4

1.3. Package Content ........................................................................................... 4

Specication .............................................................................................................. 5 2.

Panel Description ...................................................................................................... 7 3.

3.1. Front Panel .................................................................................................... 7

3.2. Rear Panel ..................................................................................................... 8

System Connections ............................................................................................... 10 4.

4.1. Safety Precautions ....................................................................................... 10

4.2. System Diagram .......................................................................................... 10

4.3. Connection Procedure ................................................................................. 10

4.4. Cascading Connections ............................................................................... 11

4.4.1. Cascading the AV Signal .............................................................................. 11

4.4.2. Cascading the Control Signal ...................................................................... 11

IR Control Modes .................................................................................................... 13 5.

5.1. IR Control ..................................................................................................... 13

5.1.1. Control far-end display device while local to Splitter .................................... 13

5.1.2. Control far-end source device while remote from Splitter ............................ 14

RS232 Control Commands ..................................................................................... 15 6.

EDID Management .................................................................................................. 17 7.

Panel Drawing ......................................................................................................... 17 8.

Troubleshooting & Maintenance .............................................................................. 18 9.

Regulatory Compliance ................................................................................................19
