Side 1/38
15
Quickstart
Manual
CAUTION:
The nuZeo oor-standing speakers have a very high weight due to
their solid construction. It is best to have two people for unpacking and
setting them up!
EN This manual is available in multiple languages.
You can nd the latest version in your
preferred language here:
www.nubert.de/en/downloads
DE Die neuesten Bedienungsanleitungen und weitere
hilfreiche Informationen nden Sie hier:
www.nubert.de/downloads-nuzeo-15
nuZeo
For the nuZeo 4, 11, and 15 models, outrigger feet with adjustable
height must be mounted before setting up the speakers! Place the
speakers upside down on a soft surface. As shown in the illustrations,
position the two outrigger feet over the threaded inserts and securely
fasten the outrigger feet to the bottom using the supplied Allen screws
and the appropriate Allen key. You can now turn the speaker over and
place it on its feet.
Caution!
Ensure not to scratch the speaker!
Do not let anything fall into the speaker through the bass reex ports!
With the knurled screw, the height of each foot can be conveniently
adjusted from above to compensate for unevenness in the surface. The
screw can be secured against rotation by turning the lock nut down
against the outrigger and tightening it slightly.
The cylindrical foot can be detached from the knurled screw to provide
an alternative setup option. This can be particularly helpful on high-pile
carpets.
Caution!
Always ensure that no damage occurs to the oor or other
components!
Assembly of the outrigger feet
1
Thank you very much for choosing Nubert speakers!
In this user manual, we explain the setup and connections as
well as the initial operation of the system. Additionally, the
complete range of functions and operations are described so
that you can achieve the best sound quality and functionality,
allowing you to fully enjoy your speakers.
Please be sure to also read the included safety instructions!
The Nubert team wishes you lots of enjoyment!
Cold, sound, and operational safety
When speakers or other electronic devices are brought from a cold
environment into a warm room, condensation can form inside, posing
a risk of damage or electric shock! Additionally, low temperatures can
aect the exibility of internal parts, such as diaphragms.
Wait at least 6 hours before turning on the device, allowing it to reach
room temperature and dry out completely! Your new speaker will
reward you with the superior sound quality you rightfully expect from
Nubert.
Knurled screw
Lock nut
Cylindrical foot
Spike
nuZeo 15 · 06 / 2024
2
Setup
2
• Rear bass reex ports should have a few centimeters of distance from
the wall or adjacent furniture fronts to avoid airow noise. A gene-
rous distance from side and rear walls also helps to reduce bass and
midrange exaggeration.
• You will achieve the most natural sound if the tweeter is approximate-
ly at ear level. However, a homogeneous sound image is still achieved
within 20 degrees above and below the tweeter axis. If your active
speakers need to be placed higher or lower, they should be angled so
that the tweeters are directed at the listening position.
• When placed on shelves, the best sound is achieved if the front edge
of the speakers is either ush with the shelf or slightly protruding.
• The speakers of a stereo pair should be placed at an identical distance
from the listening position. It is advisable to vary the distances bet-
ween the speakers and to the listening position to nd the setup that
provides the best possible sound.
• Due to the excellent radiation behavior of the nuZeo speakers, the
optimal sound image is achieved in many listening situations when
they are aligned perpendicular to the rear wall. Optionally, you can
experiment with turning the speakers slightly towards the listening
position.
Sound adjustment
To adjust the sound of the speakers to your living room or placement,
various adjustments can be made using the Nubert X-Remote app
(see page 8). Connect the app to the speakers and navigate to the
menu items depending on the desired setting:
> advanced > system hp
to reduce particularly low frequencies that tend to cause booming.
> room calibration
to perform automatic calibration of the speaker to your listening
position.
> sound
to make general sound adjustments.
nuZeo speakers are high-quality, very neutral-sounding bass reex active speakers. However, every speaker is exposed to the various inuences of
room acoustics. Therefore, please consider the following general setup guidelines:
isosceles triangle
06 / 2024 · nuZeo 15
3
