Side 1/8
nuZeo 6
Quickstart
Manual
EN This manual is available in multiple languages.
You can nd the latest version in your
preferred language here:
www.nubert.de/en/downloads
DE Die neuesten Bedienungsanleitungen und weitere
hilfreiche Informationen nden Sie hier:
www.nubert.de/downloads-nuzeo-6
nuZeo 6 · 06 / 2024
2
To mount the nuZeo 6 on a wall, an optional wall bracket is available se-
parately. This is attached using the two threaded sockets on the back of
the nuZeo 6 and allows the speaker to be swiveled around its longitudi-
nal axis. Detailed step-by-step instructions for mounting and attaching
the wall bracket can be found in its installation manual.
For vertical placement of the speaker, four vibration-damping elastic
buers are attached to its bottom, ensuring a solid stand on various
furniture pieces.
Placement
1a
Thank you for choosing Nubert speakers!
In this user manual, we explain the setup, connections, and
commissioning of the system. Furthermore, the entire range
of functions and operation is listed so that you can achieve the
optimum sound quality and functionality and fully enjoy your
speakers.
Be sure to also read the additional enclosed
safety instructions!
We wish you much joy with your new speakers!
Cold, sound, and operational safety
When speakers or other electronic devices are brought from a cold
environment into a warm room, condensation can form inside – there
is a risk of defect or electric shock! Additionally, low temperatures can
impair the mobility of parts inside the speaker, such as membranes.
Wait at least 6 hours before turning on the device until it has reached
room temperature and is dry! Your new speaker will reward you with
the superior sound quality you rightly expect from Nubert.
Wall mounting (optional)
1b
06 / 2024 · nuZeo 6
3
Placement
2
• Rear bass reex openings should have a few centimeters of distance
from the wall or adjacent furniture fronts to avoid airow noise. With a
generous distance to side and rear walls, an emphasis in the bass and
midrange area is also reduced.
• The most natural sound is achieved when the tweeter is at ear level.
However, even 20 degrees above and below the tweeter axis still re-
sults in a homogeneous sound image. If your active speakers need to
be placed higher or lower, they should be angled so that the tweeters
are directed at the listening position.
• When placed on shelves, the best sound is achieved when the front
edge of the box is ush with the shelf edges or even slightly over-
hangs.
• The speakers of a stereo pair should be placed equidistantly from the
listening position. It is advisable to vary the distances between the
speakers and the listening position to nd the placement with the
best sound result.
• Due to the excellent omnidirectional behavior of the nuZeo speakers,
the optimal sound image is achieved in many listening situations
when they are aligned perpendicular to the rear wall. Optionally, you
can experiment with turning the speakers slightly towards the listen-
ing position.
Sound adjustment
To adapt the sound of the speakers to your room or placement, various
adjustments can be made using the Nubert X-Remote App (see page 8).
Connect the app to the speakers and navigate to the following menu
items depending on the desired setting:
> advanced > system hp
to reduce particularly low frequencies that tend to drone.
> room calibration
for automatic calibration of the speaker to your listening position.
> sound
for general sound adjustments.
The nuZeo speakers are high-quality and very neutral-sounding bass reex active speakers.
However, every speaker is subject to the various inuences of room acoustics. Therefore, please observe the following general placement guidelines:
isosceles triangle
