Side 1/4
3
4 x
© 04/2009 ALL RIGHTS RESERVED. Technical changes possible. No liability for misprints.
Compatible with these Pioneer double DIN devices
Pioneer Navigation
• Hyundai H-1
Double DIN Kit contents
• (1) Mounting Brackets
• (2) Facia Plate
• (3) Fixing Screws
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
Installation Manual
Double DIN Kit
281143-H1-PIO
Installation Manual Double DIN Kit 281143-H1-PIO
1. Hyundai H-1 dashboard
6. Place the OEM front panel
Reinstall everything in reverse
order to finish installation.
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
2. Unclip the gear lever box
3. Unclip the front panel
and remove it
5. Place the Pioneer Navigation with
the facia plate at he dash board
Connect all required circuit points
Fix the facia plate to the
dashboard with four screws
4. Attach the mounting brackets
to the facia plate (see arrows)
Push the Pioneer Navigation into
the facia plate and fix it with screws
at both sides
