INSTRUCTIONS FOR USE
Pro-Ject BT Box E HD
© Pro-Ject Audio Systems -Ject BT Box E HD .4.2022 · Pro · Revision 25
2
Dear music lover,
thank you for purchasing a P -Ject Audio Systems Box E ro BT HD.
In order to achieve maximum performance and reliability you should study these instructions
for use carefully.
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make
sure that the voltage in your area meets the voltage requirements printed on the power
supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power
supply is easily accessible at all times. Never handle the device, the power supply while
your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item
containing liquid, such as a flower vase on or near the device. Never spill any liquid on
the device or the power supply. Never place any naked flame sources, such as lighted
candles on or near the device. The product shall not be used in damp or wet locations, next
to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
Make all connections whilst the product is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually
marked red, the left channel black or white.
Never use any other power supply than the one supplied with the unit.
Never connect or disconnect power supply to or from the unit whilst the power supply
is connected to the mains.
Connection to the amplifier
Connect the socket to a line input (such as ) on your amplifier. Alternatively you Line Out AUX
can use also digital to connect the unit to a D/A converter or to digital input of Optical Out a
your amplifier or AVR. Both outputs are active all the time.
Mains power connection
Connect the low voltage plug from the power supply to the socket before Power DC 18V
connecting the power supply to the mains.
© Pro-Ject Audio Systems -Ject BT Box E HD .4.2021 · Pro · Revision 25
3
BT pairing
Pairing with devices with Android OS
Open and tap on Turn on and tap on Searched devices will show Settings Bluetooth. BT Scan.
up. Tap on (Confirm pairing code if requested). Once paired it will show "BT Box E HD"
"Connected to media Audio", now you can play music from your Android device over to BT BT
Box E.
Pairing with Apple devices
Tap on tap on , turn it on, your device will automatically start searching for Settings, Bluetooth
available devices. Tap on " " and it will be connected to the Box E . Now you can BT Box E BT HD
play music.
It´s possible to use BT Box E HD also with other than above mentioned devices, pairing
procedure is always similar.
Reconnecting
If you move out of range or turn off Bluetooth BT Box E HD will disconnect from your device. To ,
reconnect simply open the Bluetooth manager and tap on "BT Box E ". If the signal is lost for HD
only a few seconds it can reconnect automatically - typically if you move out of the range and
then return back.
Adding a new phone or tablet
The unit can play music from one device at a time. If you want to switch from one device to
another, you have to disconnect existing connection to BT Box E HD and then follow the steps
for pairing with new device.
Troubleshooting
No music from speakers:
- make sure the BT Box E HD is powered
- make sure an audio cable or an optical cable is correctly connected to Box E BT HD
- make sure you are within the range
- make sure the Bleutooth is enabled and the device is connected to Box E. Volume level is BT
properly set
Technical specifications P -Ject Box E ro BT HD
Bluetooth version: 5.0
Effective working range: up to 10m (direct visibility)
Bluetooth Profile: A2DP
Supported codecs: SBC, aptX, aptX HD
Frequency: - 2480 MHz 2402
Sensitivity: - 88 dBm
Audio Output Level (nominal at 0dBFS): 2.0 Vrms
Frequency response (@-1,5dB): 20Hz 20kHz –
Channel separation (Line Out@10kHz): <-113 dB
Channel separation (Digital Out@10kHz): <-140 dB
SNR (Line out): >93dB
SNR (Digital out): >120dB
