MSO/DS1000Z series is a high-performance and economic digital oscilloscope designed for the designing,
debugging and educational requirements of the mainstream digital oscilloscope market. Wherein, the
mixed signal digital oscilloscope aimed at the embedded design and test elds is equipped with 16 digital
channels and allows users to measure analog and digital signals at the same time.
Digital O pe
es
MSO/DS1000Z
RIGOL TECHNOLOGIES, INC.
Analog channel bandwidth: 100 MHz, 70 MHz, 50 MHz
4 analog channels, 16 digital channels (for MSO1000Z and MSO
upgradable for DS1000Z Plus)
Real-time sample rate up to 1 GSa/s
Memory depth up to 12 Mpts (standard)/24 Mpts (optional)
Up to 30,000 wfms/s waveform capture rate
Up to 60,000 frames hardware real-time waveform recording
and playback functions (optional)
Innovative "UltraVision" technology
MSO eld upgradable with MSO1000Z upgrade package
(MSO upgrade option, only for DS1000Z Plus)
Various trigger and bus decoding functions
Low noise oor, vertical scale range: 1 mV/div to 10 V/div
Built-in dual-channel 25 MHz function/arbitrary waveform generator
(only for digital oscilloscope with source channels)
Various interfaces: USB Host&Device, LAN (LXI), AUX,
USB-GPIB (optional)
Compact size, light weight, easy to use
7 inch WVGA (800x480) TFT LCD, intensity graded color display
MSO/DS1000Z Series Digital Oscilloscope
Deeper Memory Depth (standard 12 Mpts, optional 24 Mpts)
Higher Waveform Capture Rate (up to 30,000 wfms/s)
Real-time Waveform Recording&Playback (up to 60,000 frames, optional)
Intensity Graded Color Display
Innovative UltraVision Technology(Analog Channel)
Models and Key Specications
Product Dimensions: Width × Height × Depth=313.1 mm × 160.8 mm × 122.4 mm
Weight: 3.2 kg ± 0.2 kg(Without Package)
7 inch WVGA (800X480) TFT display, intensity graded color display
4 analog channels
Built-in source control key
(digital oscilloscope with
source channels)
16 digital channels (for MSO1000Z and
MSO upgradable for DS1000Z Plus)
Model DS1054Z DS1074Z Plus DS1074Z-S Plus DS1104Z Plus DS1104Z-S Plus
MSO1074Z MSO1074Z-S MSO1104Z MSO1104Z-S
Analog BW 50 MHz 70 MHz 100MHz
Number of Analog Channels 4
Number of Digital Channels 16 digital channels for MSO1000Z; MSO upgradable for DS1000Z Plus
Max. Sample Rate
Analog channel: 1 GSa/s (single-channel),
500 MSa/s (dual-channel), 250 MSa/s (three/four-channel)
Digital channel: 1 GSa/s (8-channel), 500 MSa/s (16-channel)
Max. Memory Depth
Analog channel:
standard 12 Mpts (single-channel), 6 Mpts (dual-channel), 3 Mpts (3/4-channel);
optional 24 Mpts (single-channel), 12 Mpts (dual-channel), 6 Mpts (3/4-channel)
Digital channel:
standard 12 Mpts (8-channel), 6 Mpts (16-channel);
optional 24 Mpts (8-channel), 12 Mpts (16-channel)
Max. Waveform Capture Rate 30,000 wfms/s
Hardware Real-time Waveform
Recording, Playback and Analysis
Functions
Up to 60,000 frames (optional)
Standard Probes RP2200 150 MHz Passive HighZ Probe: 4 sets;
1 set RPL1116 LA Probe for MSO1000Z
Built-in Dual-channel 25 MHz Source No NoYes Yes
None
1RIGOL
4 analog channels, 16 digital channels (for MSO1000Z
and MSO upgradable for DS1000Z Plus)
UltraVision: deeper memory (standard 12 Mpts,
optional 24 Mpts)
UltraVision: up to 30,000 wfms/s waveform
capture rate
UltraVision: waveform recording and playback
functions (optional)
UltraVision: intensity graded color display
A variety of trigger functions
Optional serial bus trigger and decoding functions
(RS232/UART, I2C, SPI)
Built-in dual-channel 25 MHz source
(MSO1XX4Z-S and DS1XX4Z-S Plus)
*Do not include the 50 MHz bandwidth model
