Samsung AC140BXPDNH Bruksanvisning
Samsung
Varmepumpe
AC140BXPDNH
Les nedenfor 📖 manual på norsk for Samsung AC140BXPDNH (7 sider) i kategorien Varmepumpe. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/7
Air conditioner
User & installation manual
AC***BNPDKH/AC***BXPD*H
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this manual carefully and retain it for future reference.
2English
Contents
Safety Information 4
Safety Information 4
Checking before use 13
Using indoor unit • Storing the indoor unit • Using outdoor unit • Installing outdoor unit 13
Operation Features 14
Checking auxiliary power switch • Operating temperature and humidity 14
At a Glance 15
Indoor Unit Overview 15
Control Panel Overview 16
Indoor unit display 16
Controlling with the control panel 17
Turning on or off the air conditioner • Controlling temperature • Controlling the fan speed 17
Selecting the operation mode/Locking the control panel 18
Remote Control Overview 19
Replacing batteries • Storing the remote control 20
Remote Control Operation 21
Turning on or off the air conditioner • Operation modes 21
Controlling fan speed • Controlling temperature • Controlling air flow direction 22
Power Smart Features 23
Power Smart Features 23
Auto mode • Cool mode 23
Dry mode • Fan mode 24
Heat mode 25
Variety Smart Features 26
Turbo function • Long reach function 26
Clean function 27
Energy-Saving Operation 28
Timed on/Timed off function 28
Cleaning and Maintenance 29
Cleaning at a Glance 29
Cleaning the indoor unit exterior and outdoor unit heat exterior 29
Cleaning the filter 30
Periodical maintenance 31
Troubleshooting 32
Safety Information 34
Safety Information (Installing the Air Conditioner) 34
General information 34
Installing the unit 35
Power supply line, fuse or circuit breaker 35
3
English
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the
end of their working life. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, visit our
sustainability page available via www.samsung.com
Installation Procedure 37
Step 1 Choosing the installation location 37
Step 2 Unpacking 40
Step 3 Checking and preparing accessories 41
Step 4 Drilling a hole through a wall 41
Step 5 Taping the pipes, cables, and drain hose 41
Step 6 Purging inert gas from the indoor unit 42
Step 7 Optional: Cutting and flaring the pipes 43
Step 8 Connecting the refrigerant pipes 43
Step 9 Connecting the power and communication cables 45
Step 10 Optional: Extending the power cable 49
Step 11 Setting the indoor unit addresses and the installation options 51
Step 12 Checking the earthing 61
Step 13 Performing gas leakage test 61
Step 14 Evacuating the air 62
Step 15 Charging the refrigerant 62
Step 16 Fixing and insulating the connection part for refrigerant pipes 64
Step 17 Installing and connecting the drain hose 65
Step 18 Performing drainage test 66
Step 19 Checking the earthing 66
Step 20 Performing the final check and trial operation 67
Appendix 70
Troubleshooting 70
SPEC 72
Produkspesifikasjoner
Merke: | Samsung |
Kategori: | Varmepumpe |
Modell: | AC140BXPDNH |
