Smart-AVI SM-DVN-84X Bruksanvisning
Les nedenfor 📖 manual på norsk for Smart-AVI SM-DVN-84X (14 sider) i kategorien Bryter. Denne guiden var nyttig for 10 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/14
1 800 284 2131- - -
www.smartavi.com
USER MANUAL
Advanced 4/8 Port DVI D matrix KVM- -
SM- - - - DVN 44X 4 Port DVI D KVM Matrix, 4 Users
SM- - - - DVN 82X 8 Port DVI D KVM Matrix, 2 Users
SM- - - -DVN 84X 8 Port DVI D KVM Matrix, 4 Users
SM-DVN matrix series
Advanced 4/8 DVI I Matrix KVM 2-
TECHNICAL SPECIFICATIONS_____________________________________________________________ 3
WHAT S IN THE BOX?_____________________________________________________________________’ 4
SM- DVN FRONT AND REAR_______________________________________________________________ 4
INSTALLATION____________________________________________________________________________ 5 8-
LED s BEHAVIOR__________________________________________________________________________ 11’
SYSTEM OPERATION______________________________________________________________________ 12
TROUBLESHOOTING______________________________________________________________________ 12
TECHNICAL SUPPORT_____________________________________________________________________ 12
LIMITED WARRANTY STATEMENT________________________________________________________ 13
Table of contents
Advanced 4/8 DVI I Matrix KVM 3-
VIDEO
Format I Dual Link DVI-
Host Interface
SM-DVN-44X - - - (4) DVI I 29 pin (female) / DVI D
SM-DVN DVN- -82X / SM - - - - 84X (8) DVI I 29 pin (female) / DVI D
User Console
Interface
SM-DVN-82X - - - (2) DVI I 29 pin (female) / DVI D
SM-DVN DVN- -44X / SM - - - - 84X (4) DVI I 29 pin (female) / DVI D
Max Resoluon 2560 x 1600 @ 60Hz; 3840x2160 @ 30Hz (w/HDMI DVI adapter) -to-
DDC - 5 volts p p (TTL)
Input Equalizaon Automac
Input Cable Length Up to 20 .
Output Cable Length Up to 20 .
AUDIO
Input (4) / (8) Connector Stereo 3.5mm Female
Output (2) / (4) Connector Stereo 3.5mm Female
CONTROL
Front Panel Push Buons with LED indicators
RS232 Via Serial @ 115200 bps
Hot Keys Via Keyboard
POWER
Power Requirements 12V DC, 3A (minimum) power adapter with center pin posive polarity. -
ENVIRONMENT
Operang Temp 32° to 104° F (0° to 40° C)
Storage Temp 4° to 140° F ( 20° to 60° C) - -
Humidity 0 80% RH, non condensing - -
OTHER
Emulaon Keyboard, Mouse and Video
Control Front Panel Buons
Technical Specifications
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Type A to B SM-DVN-44X (4)
SM-DVN DVN- -82X / SM - 84X (8)
User Console Interface (2) USB Type A for keyboard and mouse connecon only -
Produkspesifikasjoner
