testo 565i Vacuum Pump
Instruction manual
Contents
Contents
1 About this document 3 ...........................................................................
2 Safety and disposal .............................................................................. 4
2.1 Product-specic information ................................................................... 4
2.2 Disposal . 7 ................................................................................................
3 Intended use ......................................................................................... 7
4 Product description 8 .............................................................................
4.1 Overview ................................................................................................ 8
5 First steps ........................................................................................... 10
5.1 Switching the instrument on and o ..................................................... 10
5.2 Evacuation with a manifold ................................................................... 12
5.3 Direct Evacuation ................................................................................. 16
6 Maintenance ........................................................................................21
6.1 Cleaning instruments ............................................................................ 21
6.2 Keeping connections clean ..................................................................21
6.3 Choosing correct pump oil .................................................................... 21
6.4 Changing pump oil ............................................................................... 22
6.5 Replacing oil mist trap .......................................................................... 22
7 Technical data .................................................................................... 23
7.1 Version 7 CFM ..................................................................................... 23
7.2 Version 10 CFM ................................................................................... 24
8 Tips and assistance ........................................................................... 24
8.1 Accessories .......................................................................................... 24
9 Support ...............................................................................................25
9.1 Trouble shooting ...................................................................................25
9.2 Error codes ........................................................................................... 26
1 About this document
3
1 About this document
• The instruction manual is an integral part of the instrument.
• Pay particular attention to the safety instructions and warning advice in order
to prevent injury and damage to the product.
• Please read this instruction manual through carefully and familiarize yourself
with the product before putting it to use.
Symbols and writing standards
Display
Explanation
Note: basic or further information
Warning advice, risk level according to the signal word:
Warning! Serious physical injury may occur.
Caution! Minor physical injury or damage to the equipment may
occur.
Careful! Possible damage to equipment.
- Implement the specied precautionary measures.
1
2
…
Action: several steps, the sequence must be followed
Result of an action
✓
✓
✓
✓✓
Requirement
Menu
Elements of the instrument, the instrument display or the
program interface.
[OK]
Control keys of the instrument or buttons of the program
interface.
