Hardware Installation Refer to the application scene graph below
Notice
1. The switch should be used indoor only.
2. Use the Power cord comes with the switch.
3. Set the device on a flat surface strong enough to support the entire weight
of the device with all fittings.
4. Don’t place heavy objects on the switch.
Use Ethernet cable to connect router to Switch (LAN port to LAN port)
Use Ethernet cable to connect PC or Laptop’s RJ45 port to Switch
Plug one end of the power cord into switch’s AC power jack and then
other end to wall socket.
Ethernet Switch
接線方式 請參考下列說明
使用第二條網路線，連接交換器 任一網路孔 與電腦的網路孔。( )
連接電源。
使用網路線，連接交換器 任一網路孔 與 線分享器 數據機的( ) 无/
區域網路孔。
乙太網路交換器( )以SW24为例
網路線
網路線
網路線
無線分享器/數據機
注意
1. 請於室內使用
2. 請使用原廠附贈之電源線
3. 請放置於平坦且堅固之桌面或妥善安裝於機架上
4. 請勿放置重物於交換器上方
V2.0 | 1808
Router
Quick Installation Guide
Ethernet Switch
Suitable for: SW16,SW24,SG16
For more information, please go to www.totolink.net
Information in this document is subject to change without prior notice.
Copyright ⓒ TOTOLINK., All rights reserved.
台灣用戶請參閱背面繁體中文說明
Copyright TOTOLINK，說明內容如有錯誤或更改，恕不另行通知，敬請見諒。ⓒ
台灣地區
客服免費專線: 0800-885799
手機請撥付費電話: 02-22215559
客服信箱: fae-tw@zioncom.net
更多產品資訊，請參考 www.totolink.tw
台灣吉翁電子股份有限公司
地址: 新北市中和區中正路872號9樓之1
聯絡電話: 02-22215559
Before Installation
Checking Package Contents
1* 16/24 ports Ethernet Switch
1* Power Cord
1* Quick Installation Guide
2* Mounting Brackets and the fittings
Appearance
(Take SW24 for Example)
LED Indicators
Link/Act
(1~16 or 1~24)
POWER
LED Indicator Description
The indicator lights green when powered on
The corresponding indicator lights green when connected
to other device, flashes green during data transfer
產品介紹
包裝內容
1* 16/24埠乙太網路交換器
1* 電源線
1* 快速安裝手冊
2* 安裝支架及配件
產品外觀
以 為例SW24
LED燈號說明
POWER
LED指示燈 狀態
燈亮
燈亮
熄滅
熄滅
說明
電源接通綠燈亮起
未連接電源
連接網路孔綠燈亮起, 資料傳輸綠燈閃爍
網路孔未連接
Link/Act
(1~16 或 1~24)
SW16 / 16埠乙太網路交換器
SW24 / 24埠乙太網路交換器
SG24 / 16埠Giga極速乙太網路交換器
