Side 1/25
i
SERVICE
MANUAL
Alpha- 3R
Direct Thermal Portable Printer
ii
Contents
1. FUNDAMENTAL OF THE SYSTEM ................................ 2
1.1 Overview 2 ...........................................................................................................
2. ELECTRONICS ............................................... 3
2.1 Summary of Board Connectors ....................................................................... 3
3. MECHANISM ................................................ 7
3.1 Replacing the Platen Roller (Including media cover) ..................................... 7
3.2 Replacing the Keys Control Board .................................................................. 9
3.3 Replacing the Bluetooth Module (Option) ..................................................... 10
3.4 Replacing the Media Holder Assembly ......................................................... 11
3.5 Replacing the Main Board Assembly ............................................................ 13
3.6 Replacing the Print Head Assembly .............................................................. 14
3.7 Replacing the Stepping Motor ....................................................................... 15
3.8 Replacing the black mark sensor assembly ................................................. 16
3.9 Replacing the Wi-Fi Module (Option) ............................................................ 17
3.10 Replacing the Open Sensor .......................................................................... 18
4. TROUBLESHOOTING ......................................... 22
4.1 Common Problems ......................................................................................... 22
5. Maintenance ............................................... 24
Revise History ................................................ 25
2
1. FUNDAMENTAL OF THE SYSTEM
1.1 Overview
Front View
1. LED indicator
2 eed button . F
3. Power on/o button
4. Media cover release button
5 Media holder adjustment knob .
6. Media cover
2
3
5
6
