Side 1/2
WALL LOUVER
6โ
7โ
8โ
8 ๎โ๎โ
Back
View
1 ยฝโ Flange
WALL LOUVER
11โ
11โ
Back
View
1 ยฝโ Flange
WALL UVERLO
13โ
13โ
Back
View
1 ยฝโ Flange
RECTANGULAR WALL UVERLO
3 ยผโ
10โ
8 ยฝโ
6โ
1 ยฝโ FLANGE
2โ FLANGE
LOW PROFILE ROOF JACK
(MAXIMUM 4/12 PITCH)
6 ยฝโ
16 ยพโ
16 ยพโ
LOW PROFILE ROOF JACK
(MAXIMUM 4/12 PITCH)
10 ยฝโ
22 ยฝโ
20 ยพโ
ADJUSTABLE ELBOW
6โ
7โ
8โ
VP513 - 8 ยฝโ
VP514 - 9 ๎โ๎๎โ
VP515 - 10 ๎โ๎โ
ROUND DUCT PIPE
36โ
6โ
7โ
8โ
3 ยผโ RECTANGULAR DUCT PIPE
30โ
10โ
12โ
16โ
3 ยผโ
6โ RECTANGULAR DUCT PIPE
24โ
8 ยฝโ
6โ
OFFSET L & R TRANSITION
FOR ISLAND BLOWERS
8โ
12โ
5โ
16โ
SIDE VENT TRANSITION L & R
FOR ISLAND BLOWERS
19โ
8โ
16โ 5โ
โYโ TRANSITION
18โ
10โ
12โ
OFFSET KIT - ROUND
16โ
11โ
6โ
7โ
10 ยฝโ
OFFSET KIT - RECTANGULAR
16โ
11โ
6โ
11โ
3 ยผโ 10โ
STANDARD ISLAND TRANSITION
8โ
9โ
16โ 5โ
CLUSTER BLOWER TRANSITION
18 ยฝโ
12โ
11 ยผโ
BACK/SIDE VENT ELBOW
12โ
6โ
16โ
8โ Round
8 ยฝโ
3 ยผโ x 10โ BACK VENT ELBOW
4 ยผโ 10โ
14โ
3 ยผโ
3 ยผโ
MULTI-BLOWER TRANSITION
VP562 - 17 ยฝโ
VP563 - 16 ยฝโ
10โ
12โ
VP562 - 23 ยผโ
VP563 - 30 ยฝโ
3 ยผโ x 10โ TO 7โ TRANSITION
7โ
7 ยฝโ
3 ยผโ
10โ
M1200 STANDARD TRANSITION
10โ
9โ
8โ
21โ
LOW PROFILE ROOF JACK
(MINIMUM 4/12 PITCH)
6 ยฝโ
16 ยพโ
16 ยพโ
LOW PROFILE ROOF JACK
(MINIMUM 4/12 PITCH)
10 ยฝโ
22 ยฝโ
20 ยพโ
Page 1
THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE.
email: customer_service@ventahood.com website: www.ventahood.com
7/31/18
MODEL DESCRIPTION
VP526 6โ Round
VP527 7โ Round
VP528 8โ Round
MODEL DESCRIPTION
VP554 10โ Round
MODEL DESCRIPTION
VP555 12โ Round
MODEL DESCRIPTION
VP538 6โ x 8-1/2โ
VP560 3-1/4โ x 10โ
MODEL DESCRIPTION
VP539 6โ Round
VP540 7โ Round
VP541 8โ Round
MODEL DESCRIPTION
VP552 10โ Round
VP553 12โ Round
MODEL DESCRIPTION
VP539-HP 6โ Round
VP540-HP 7โ Round
VP541-HP 8โ Round
MODEL DESCRIPTION
VP552-HP 10โ Round
VP553-HP 12โ Round
MODEL DESCRIPTION
VP513 6โ Round
VP514 7โ Round
VP515 8โ Round
MODEL DESCRIPTION
VP561 8โ to 6โ x 8-1/2โ
MODEL DESCRIPTION
VP559 3-1/4โ x 10โ
MODEL DESCRIPTION
VP521 3-1/4โ x 10 to 7โ
MODEL DESCRIPTION
VP562 6โ & 8โ to 10โ
VP563 8โ & 8โ to 12โ
MODEL DESCRIPTION
VP566 M1200 Transition
MODEL DESCRIPTION
VP565 5โ x 16โ to 8โ Rnd
MODEL DESCRIPTION
VP564 8โ & 8โ to 12โ
MODEL DESCRIPTION
VP542 Top Left
VP543 Top Right
MODEL DESCRIPTION
VP544 Side Left
VP545 Side Right
MODEL DESCRIPTION
VP529 6โ Rnd to 7โ Rnd
MODEL DESCRIPTION
VP550 6โ to 3-1/4โ x 10โ
MODEL DESCRIPTION
VP517 8โ & 8โ to 12โ
VP518 6โ & 8โ to 12โ
VP551 6โ & 8โ to 10โ
MODEL DESCRIPTION
VP500 6โ Round
VP501 7โ Round
VP502 8โ Round
MODEL DESCRIPTION
VP504 3-1/4โ x 10โ
VP505 3-1/4โ x 12โ
VP506 3-1/4โ x 16โ
MODEL DESCRIPTION
VP507 6โ x 8-1/2โ
Page 2
THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE.
email: customer_service@ventahood.com website: www.ventahood.com 7/31/18
MOTORS
PART NO. DESCRIPTION
P1301-1 SINGLE SPEED WHITE MOTOR (CW)
P1301-2 TWO SPEED WHITE MOTOR (CW)
P1302-1 BLACK MOTOR (CCW)
P1315 V-LINE MOTOR
P1900 ADAPTER (AMP PLUG/TWO PRONG PLUG)
BLOWER WHEELS
PART NO. DESCRIPTION
P1305 WHITE BLOWER WHEEL (CW)
P1306 BLACK BLOWER WHEEL (CCW)
P1307 V-LINE BLOWER WHEEL
BLOWER HOUSINGS
PART NO. DESCRIPTION
SPECIFY HOOD COLOR
P1029 B100/T200 BLOWER HSG w/DAMPER
P1029E B100/T200 EZ CLEAN HSG w/DAMPER
P1028 B200/T400 BLOWER HSG w/DAMPERS
P1028E B200/T400 EZ CLEAN HSG w/DAMPERS
P1030 T200 REVERSE BLOWER HSG w/DAMPER
P1030E T200 REVERSE EZ CLEAN HSG w/DAMPER
P1021 V-LINE BLOWER COVER (PAN)
BLOWER SHIELDS
PART NO. DESCRIPTION
P1025 B100/T200 SHIELD, PAINTED
P1025E B100 EZ CLEAN SHIELD, PAINTED
P1025E-I T200 EZ CLEAN SHIELD, PAINTED
P1027 B100/T200 SHIELD, STAINLESS
P1027E B100 EZ CLEAN SHIELD, STAINLESS
P1027E-I T200 EZ CLEAN SHIELD, STAINLESS
P1024 B200/T400 SHIELD, PAINTED
P1024E B200 EZ CLEAN SHIELD, PAINTED
P1024E-I T400 EZ CLEAN SHIELD, PAINTED
P1026 B200/T400 SHIELD, STAINLESS
P1026E B200 EZ CLEAN SHIELD, STAINLESS
P1026E-I T400 EZ CLEAN SHIELD, STAINLESS
P1610P NICKEL SHIELD SCREW
SWITCHES AND CONTROLS
PART NO. DESCRIPTION
P1431 SWITCH FOR SINGLE SPEED BLACK MOTOR
P1432 SWITCH FOR FLUORESCENT LIGHT
P1433 SWITCH FOR TWO SPEED WHITE MOTOR
P1434 SWITCH FOR HALOGEN LIGHTS
P1435 LED ROCKER SWITCH
P1409 MOMENTARY SWITCH (TILT/TLH HOODS)
P1418 DIMMER SWITCH (CAN LIGHTS)
P1419 ROTARY SWITCH (HEAT LIGHTS)
P1422 KNOB FOR ROTARY SWITCH (SET SCREW)
P1425 REMOTE BLOWER SPEED CONTROL (HOOD)
P1460 ROTARY SWITCH - B100/LED LIGHTS
P1465 ROTARY SWITCH - B200/T200/T400(2)
P1470-1 MAGIC LUNG ROTARY BLOWER KNOB
P1475-1 MAGIC LUNG ROTARY LIGHT KNOB
P1350-1 DIMMER PACK FOR INTEGRATED LED BULB
M LINE COMPONENTS
PART NO. DESCRIPTION
P1440 M LINE BLOWER SWITCH
P1445 M LINE BLOWER SWITCH KNOB
P1450 M LINE LIGHT SWITCH
P1455 M LINE LIGHT SWITCH KNOB
P1456 M600 WIRING HARNESS
P1457 M1200 WIRING HARNESS
LIGHT BULBS
PART NO. DESCRIPTION
P1110 GU10 HALOGEN BULB, 50 WATT
P1111 GU10 LED BULB
P1120 F15/T8 FLUORESCENT BULB, 15 WATT
P1130 PAR20 HALOGEN BULB, 50 WATT
P1350 INTEGRATED LED BULB
LIGHT FIXTURE COMPONENTS
PART NO. DESCRIPTION
P1103 LEFT LAMPHOLDER
P1104 RIGHT LAMPHOLDER
P1105 FS-2 STARTER
P1106 STARTER SOCKET
P1123 PAR20 HALOGEN LAMP SOCKET
P1124 GU10 LAMP SOCKET
P1127 FLUORESCENT LIGHT DIFFUSER
REPLACEMENT FILTERS
PART NO. DESCRIPTION
P1506 SS BAFFLE (16โ x 20โ x 1-1/2โ)
P1506A SS BAFFLE (10โ x 20โ x 1-1/2โ)
P1530 M LINE BAFFLE FILTER - 12โ x 12โ
P1531 M LINE FILTER FILLER PLATE - 6โ x 12โ
BACK DRAFT DAMPERS
PART NO. DESCRIPTION
P1031 NYLON POLYMER DAMPER
P1040 B100/T200 METAL DAMPER
P1041 B200 METAL DAMPER
P1042 V-LINE DAMPER
REMOTE BLOWER COMPONENTS
PART NO. DESCRIPTION
P1425 REMOTE BLOWER SPEED CONTROL (HOOD)
P1510 RM1000 BLOWER WHEEL
P1515 RM1000 MOTOR
P1520 RM1500 BLOWER WHEEL
P1525 RM1500 MOTOR
OTHER MISCELLANEOUS ITEMS
PART NO. DESCRIPTION
P1039 FLAP STAY FOR TILT/TLH HOODS
AW101 T-HANDLE, 1/8โ ALLEN WRENCH
AW102 STANDARD, 1/8โ ALLEN WRENCH
P1424 SENSASOURCE THERMOSTAT ASSY
SS KIT STAINLESS STEEL SCRATCH REPAIR KIT
SS64 STAINLESS STEEL MAGIC (CAN)
CP101 RED BEARยฎ COPPER POLISH
P1316 3-1/4โ x 10โ COLLAR FOR V-LINE
P1317 BACK PLATE FOR V-LINE
