Aduro 22.4 Lux wall mounting
1. Dismount the top
plate. Afterwards,
dismount the safety
bracket and pull the
wall bracket away
from the stove.
2. Dismount the
heat shield.
If using the back
outlet, please
remove the
round circle
from
the heat shield
and the wall
bracket.
3. Mount the wall
bracket securely in the
desired position.
ONLY USE FIXING
MATERIALS, WHICH
CANNOT MELT.
If using the back
outlet, the pipe must
go precisely 35 mm
out of the wall.
4. IMPORTANT:
mount the heat
shield on the wall
bracket again.
5. Place the stove
on the lower rails
of the bracket and
push the stove in
place.
6. Secure the stove by
mounting the safety
bracket on top of the
stove again. You can
now remount the top
plate.
7. Mount the safety
plate under the
stove.
Note: You will nd
plate and screws for
the assembly in the
ashpan.
2
