Side 1/2
Dual-head cable USB-A to USB-C
Câble de chargement USB à double embout
Zweifach-USB-Ladekabel
DESIGN
SERIES
T M
Potential choking hazard to children. This light is extremely bright—do not aim directly into eyes. UK ONLY: When used for cycling, this light should be used in conjunction with a British Standard 6102/3 WARNING:
cycle light. This product contains Bisphenol A which is known to the State of California to cause reproductive harm. WARNING:
FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase
the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician
for help. Shielded interface cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules. Specifications and designs are subject to change
without any notice or obligation on the part of the manufacturer.
Customer Service: 1-800-456-2355
GRID™ Rear
LUMINATE™ 360
USB Rechargeable Light Set
#7149584
QUICK START
1. Push button to power on.
2. SINGLE-Click to cycle modes.
3. Hold 1 second to power off, light powers back on in the last mode used.
FUEL GAUGE
Color LEDs in the power button help you monitor your light battery power,
indicating that it’s time to charge your light.
USB CHARGING
Fully charge the light before first use. The light indicator will flash when
charging. When charging is complete the fuel gauge will be a steady green.
_____________________________________________________________
Dayblazer™ 550 FRONT
Blitz: 1 hour at 550 Lumens
High: 1.5 hours at 275 Lumens
Low: 5 hours at 75 Lumens
Pulse: 5.5 hours at 100 Lumens
Strobe: 12 hours at 65 Lumens
MOUNTING
Pull strap around handlebar and attach to hook. Fits most handlebars.
Fits handlebars 22-35mm and most bike helmets (mount sold separately).
INCLUDES (1) Li Po Battery, (1) OSRAM 3737 LED
_____________________________________________________________
Grid™ Rear
Solid: 1.5 hours at 40 lumens
Pulse: 4 hours at 30 lumens (+2 hours *auto-eco)
Strobe: 7.5 hours at 20 lumens (+2 hours *auto-eco)
ECO Flash: 20 hours at 20 lumens
MOUNTING
Fits most handlebars, seatposts, seatstays, racks, and bag light loops.
INCLUDES (1) Li Po Battery, (1) Silicone strap
_____________________________________________________________
GriD™ Side
Solid: 1.5 hours at 110 Lumens
Pulse: 4 hours at 55 Lumens (+2 hours *auto-eco)
Strobe: 6 hours at 40 Lumens (+2 hours *auto-eco)
ECO: 20 hours at 40 Lumens
*Auto-eco switches on automatically at the end of Pulse
and Strobe run times for an additional 2hrs of runtime.
MOUNTING
Pull 0-ring around fork and secure to mounting hook.
INCLUDES (2) Li Po batteries, (4) 0-rings
_____________________________________________________________
ACCESSORIES & REPLACEMENT PARTS
• Dayblazer 550: Action-camera helmet mount #7105045
• Dayblazer 550: Handlebar mount #7105046
• Grid Side Light 0-rings (2) 65mm, and (2) 35mm #7115221
• Grid light silicone strap #7157546
• Dual head USB-C charging cable #7157548
User’s Manual
Manuel de l'Utilisateur
Benutzerhandbuch
Power button / Fuel gauge
Bouton d'alimentation / Jauge de charge
Einschalttaste / Kapazitätsanzeige
DAYBLAZER™ 550 Front GRID™ Side
100-75%
75-25%
‹25-0%
GRID™ Side 0-rings
(2) 65mm, Large fork
(2) 35mm, Small fork
Silicone strap / Sangle en silicone / Silikonband
GRID™ Rear
AVERTISSEMENT:
Danger possible d’étouffement pour les
enfants, Cette lampe est extrêmement brillante – ne pas diriger
le faisceau directement dans les yeux.
LUMINATE
™
360
Wiederaufladbares USB-Seitenlicht Art.-Nr. #7149584
SCHNELLSTART
1. Zum Einschalten Taste drücken.
2. Klicken, um zwischen den Modi zu wechseln.
3. Zum Ausschalten die Taste 1 Sekunde lang gedrückt halten.
Das Licht schaltet sich im zuletzt verwendeten Modus wieder ein.
KAPAZITÄTSANZEIGE
Farbige LEDs in der Einschalttaste zeigen an, dass es an der Zeit
ist, den Akku der Lampe aufzuladen
.
USB-AUFLADUNG
Vor dem ersten gebrauch muss die lampe vollständig aufgeladen
werden. Die Leuchtanzeige blinkt während des Ladevorgangs.
DB550™ LUMENS RUNTIME
BLITZ 550 1,0 Std.
Stark 275 1,5 Std.
Schwach
75 5,0 Std.
Impuls
100 5,5 Std.
Stroboskop
65 12 Std.
___________________________________________________
GRIDREAR™ LUMENS RUNTIME *AUTO-ECO
Konstant 40 1,5 Std. -
Impuls 30 4 Std. + 2h
Stroboskop 20 7,5 Std. + 2h
ECO 20 20 Std. -
*Auto-Eco schaltet sich automatisch am Ende der Impuls- und
Strobe-Laufzeiten für weitere 2 Stunden Laufzeit ein.
___________________________________________________
GRIDSIDE™ LUMEN BETRIEBSDAUER *AUTO-ECO
Konstant 110 1,5 Std. -
Impuls 55 4,0 Std. +2,0 Std.
Stroboskop 40 6,0 Std. +2,0 Std.
ECO 40 20 Std. -
*Auto-Eco schaltet sich automatisch am Ende der Impuls- und
Strobe-Laufzeiten für weitere 2 Stunden Laufzeit ein.
BEFESTIGUNG
Den O-Ring um die Gabel ziehen und am Befestigungshaken
einhängen.
(2) O-Ringe (65 mm) für große Gabel
(2) O-Ringe (35 mm) für kleine Gabel
ZUBEHÖR
(Vendus séparément)
• Actionkamera-Helmhalterung, Art.-Nr. 7105045
• Dayblazer Lenkerhalterung vorn, Art.-Nr. 7105046
LUMINATE
™
360
Lampe latérale rechargeable par USB #7149584
DÉMARRAGE RAPIDE
1. Appuyez sur le bouton pour l'allumer ghgg
2. Appuyez pour faire défiler les modes
3. Maintenez le bouton enfoncé pendant 1 seconde pour
l'éteindre. La lumière se rallumera sur le dernier mode utilisé.
JAUGE DE CHARGE
Les LED de couleur du bouton d'alimentation vous aident à contrôler la
batterie de votre lampe pour vous indiquer qu'il est temps de la recharger.
CHARGEUR USB
Veillez à charger entièrement la lampe avant la première
utilisation. Le voyant lumineux clignote durant la charge.
DB550™ LUMENS RUNTIME
ÉCLAIR
550 1h
Élevé
275 1.5h
Faible
75 5h
Pulse 100 5.5h
Stroboscopique
65 12h
___________________________________________________
GRID™ REAR LUMENS RUNTIME *AUTO-ECO
Élevé 40 1,5 h -
Pulse 30 4 h + 2h
Stroboscopique 20 7,5 h + 2h
ECO 20 20 h -
*Auto-Eco s'allume automatiquement à la fin des temps de fonctionne-
ment Pulse et Strobe pour 2 heures supplémentaires de fonctionnement.
___________________________________________________
GRID™ SIDE LUMENS TEMPS D'UTILISATION *AUTO-ÉCO
Élevé 110 1,5 h -
Pulse 55 4 h + 2 h
Stroboscopique 40 6 h + 2 h
ÉCO 40 20 h -
*Auto-Eco s'allume automatiquement à la fin des temps de fonctionne-
ment Pulse et Strobe pour 2 heures supplémentaires de fonctionnement.
INSTALLATION
Placez l'anneau autour de la fourche et fixez-la au crochet de
fixation. (2) Anneaux de 65 mm, grandes fourches
(2) Anneaux de 35 mm, petites fourches
COMPREND
(2) Batterie LiPo, (1) Câble de chargement USB à double embout (4) Anneaux
ACCESSOIRES
(Vendus séparément)
• Fixation de caméra embarquée pour casque #7105045
• Fixation de lampe avant Dayblazer pour guidon # 7105046
