Side 1/6
deluxe hand-held
shower massager
masajeador para duchador
manual Deluxe
douche massage de
luxe à main
www.drivemedical.com
www.drivemedical.com
Existing Shower Head
Shower Head
B
Anti-Siphon Device
C
installation instructions
1. Remove the old shower head leaving
shower arm.
2. Screw Anti-Siphon Device (A) into
existing shower head.
3. Place rubber gasket (included) into
Rotator Joint (B) and screw Rotator
Joint into the other end of the Anti-
Siphon Device.
4. Locate the end of the hose that has
a bolt on the end and screw it onto the
Rotator Joint (B).
5. Screw the other end of hose into the
new shower head (C).
6. Hang shower head on bracket end of
Anti-Siphon Device (A) when
not in use.
A
Item # 12045
Escutcheon
Cabeza Del Duchador Ya Existente
Cabeza Del
Duchador
B
Dispositivo Anti-Sifón
C
1. Quite la cabeza del duchador viejo
dejando el brazo del duchador.
2. Enrosque el dispositivo anti-sifón (A) en la
cabeza del duchador ya existente.
3. Coloque la junta de goma (incluida) en la
unión giratoria (B) y enrosque la unión
giratoria en el otro extremo del dispositivo
anti-sifón.
4. Ubique el extremo de la manguera que
tiene un tornillo en la punta y enrósquelo
en la unión giratoria (B).
5. Enrosque el otro extremo de la manguera
en la nueva cabeza del duchador (C).
6. Cuelgue la cabeza del duchador en el
extremo del soporte del dispositivo
anti-sifón (A) cuando no está en uso.
A
Item # 12045
Campana
instrucciones de instalación
