Side 1/4
• direct heaters
• rediant panels
• electric fl oor heating
Intended for:
INSTALLATION AND LOCATION
Install the thermostat at a suitable place where its operation cannot be affected by direct fl ow
of hot air from the heater, sunshine or other disturbing effects. Neither install it on an external
wall. The installation height should be approx. 1.5 m above the fl oor. Place the thermostat in
the “reference room”, such as the living room (the heating source will switch according to the
temperature in this room).
The installation must only be done by a properly qualifi ed person!
Before installation, disconnect the power supply!
1) Switch off the main circuit breaker.
2) Loosen the locking screw and remove the front part of the thermostat with the
electronics (Fig. 1).
3) Fix the back part of the thermostat to the wall (Fig. 2).
4) Connect conductors to the terminals acc. to the wiring diagram below, see Fig. 3.
5) Put on the front part of the thermostat with LCD and ensure the thermostat with the
locking screw against splitting.
6) Switch on the main circuit breaker. If everything is OK, the LCD shows the current
temperature.
INSTALLATION PROCEDURE
DESCRIPTION OF THE FUNCTION
The LCD backlight is activated by the fi rst pressing of
or button! Next pressing of this buttons change
the required temperature. Thermostat allows to set-up
temperature in range 3 °C to 39°C.
This temperature can be change by pressing of
and buttons or you can switch between two
temperature levels by pressing / buttons.
For you can set up e.g. 19°C, for e.g. 23°C.
Then you can only in the morning set and in the
evening .
If power failure occurs, then after its restoration is ther-
mostat set on mode on 18°C.
The factory-set is:
18°C
21°C
Theese values are always set up after power failure.
indication of heating
switched ON
Push-button for
temperature
damp
Temperature
mode switch
/
Push-button for
temperature
increase
Fig.1 Loosen the locking screw and remove
the thermostat electronics.
Fig.2 Fix the back part of the thermostat
to the wall.
Fig.3 Connect the inlet wires according
to the diagram.
Fig.4 Put the electronics part onto the bottom
part and ensure it with the locking screw.
L
N
HEATING
max. 16 A
UNUSED
holes for installation screws
Produkspesifikasjoner
| Merke: | Elektrobock |
| Kategori: | Termostat |
| Modell: | PT14 |
