EMOS P5686 Bruksanvisning
Les nedenfor 📖 manual på norsk for EMOS P5686 (46 sider) i kategorien Termostat. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/46
P5686
GB Immersion Thermostat
CZ Jímkový termostat
SK Jímkový termostat
PL Termostat do zabudowy
HU Merülőhüvelyes csőtermosztát
SI Potopni termostat
RS|HR|BA|ME Potopni termostat
DE Thermostat mit Tauchhülse
UA Термостат з капілярною трубкою
RO|MD Termostat cu teacă
LT Panardinamasis termostatas
LV Iegremdējams termostats
EE Sukeltermostaat
BG Потопяем термостат
FR|BE Thermostat à plongeur
IT Termostato a pozzetto
NL Thermostaat met opvangbak
ES Termostato de inmersión
2101110000_31-P5686_00_01_WEB 105 × 148 mm
www.emos.eu
2
2
1
1
2
3
4
5
6
7
8
3
GB | Immersion Thermostat
Properties
Immersion thermostat with display
Temperature range 5 °C – 80 °C (0.1 °C resolution)
Simple electrical connection via screwless terminals
Specications
Switched load: max. 230 V AC; 5 A for resistive load; 1.5 A for inductive load
Power supply: 230 V AC
Temperature control range: 5 °C – 80 °C
Temperature measurement: 5 °C to 80 °C with 0.1 °C resolution accuracy ±1 °C
Temperature setting: 5 °C to 80 °C in 0.1 °C increments
Temperature dierential setting: 0.1 °C to 15 °C with 0.1 °C resolution
Thermowell dimensions: 58 mm, Ø 8 mm, ½ inch thread
Enclosure rating: IP40
Thermostat Description (See Fig. 1)
1 – activation indicator LED
2 – display
3 – up arrow (increase value)
4 – down arrow (decrease value)
5 – on/o/function setting button
6 – screws
7 – thermowell locking screw
8 – thermowell
Installation (See Fig. 2)
The thermowell is tted with a 1/2" external thread, which is to be screwed into the coupling collar
tted at the spot where you need to measure temperature (piping, tank). The thermostat’s sensor is
inserted into the thermowell so that the body of the thermostat is in contact with the thermowell. It
is then secured in this position using the screw on the plastic collar.
Electrical Connection
1. Remove the 2 screws on the front housing of the thermostat.
2. Carefully remove the front housing.
3. Connect in accordance with the following diagram (see Fig. 2):
• Pump
• Power – 230 V
• Jump – jumper
• PE – protective earth, prevents injury by electric current
4. The thermostat features a screwless conductor connection. Press downwards onto the top plastic
connector with e.g. a screwdriver. The terminal contact will release. Plug in the conductor. Repeat
the process for all conductors needed for connection. Replace the screws.
Installation should be carried out by a qualied person!
Installation must always be performed when power is turned o; follow safety specications. Main-
tain the maximum switched load listed in technical specications! The manufacturer is not liable
for inexpert installation.
