Side 1/19
ZS2912
ZS2922
ZS2932
ZS2942
1531291200_31-ZS2912_00_01_WEB 148 × 210 mm zdroj indd: 1531291200_31-ZS2912_00_01_WEB
www.emos.eu
GB LED Floodlight
CZ LED reektorové svítidlo
SK LED reektorové svietidlo
PL Naświetlacz LED
HU LED reektor
SI LED reektor
RS|HR|BA|ME LED reektor
DE LED Reektor
UA Світлодіодний прожектор
RO|MD Lampă reector cu LED
LT LED prožektorius
LV LED prožektors
EE LED prožektor
BG Светодиоден прожектор
FR|BE Projecteur à LED
IT Faretto a LE
NL LED-schijnwerper
ES Foco reector LED
2
Type Input Voltage Max.
Power Life Span Luminous
Flux Dimensions Weight Maximum Projected
Area
ZS2912
220–240 VAC
50 Hz
10 W 25 000 h 1 000 lm 105 × 143 × 64 mm 0.20 kg 0.01 m2
ZS2922 20 W 25 000 h 2 000 lm 135 × 165 × 64 mm 0.23 kg 0.02 m 2
ZS2932 30 W 25 000 h 3 000 lm 165 × 185 × 64 mm 0.36 kg 0.03 m 2
ZS2942 50 W 25 000 h 5 000 lm 210 × 217 × 64 mm 0.50 kg 0.03 m 2
ZS2912
ZS2922
ZS2932
ZS2942
143 mm
105 mm 64 mm
135 mm 64 mm
165 mm
165 mm 64 mm
185 mm
210 mm 64 mm
217 mm
3
GB | LED Floodlight
LED Floodlight is designed for indoor and outdoor use to be mounted on a rm ground.
Ingress Protection IP54 – for outdoor use
PIR sensor – specication:
Time-delay: min. 10 s ±5 s – max. 10 min ±1 min
Detection angle: 120°
Ambient light: 5 lux –> 2 000 lux (adjustable)
Detection distance: 5–10 m
Detection motion speed: 0.6–1.5 m/s
PIR sensor setting:
Detection eld is possible to be set by moving the motion sensor switch to the left and to the right.
Adjustment of the ambient light (sensitivity)
You can choose at what luminosity will the sensor go on by a button A (see picture no. 4).
Time-delay
You can set the time-delay of the lamp by a button B (see picture no. 4)
Detection range
The distance at which the sensor responds to movement can be set using the control C.
Mounting
Mount the Floodlight rmly onto a solid basis, for example a wall (g. 1, 2, 3).
Installation height 2.3–3 m.
Connect a power cable for connection to a 220–240 V~ power network.
The cable must not be plugged into the power network during installation of the spotlight.
Direct the Floodlight as shown on g. 1 and 2.
L – brown – live wire
G – green&yellow – earth wire (ground)
N – blue – neutral wire
Maintenance instructions:
Before maintenance, switch o the Floodlight and wait until it is cooled.
Clean it with a soft moistened cloth.
Never submerge the Floodlight in water or other liquids.
During maintenance, observe general rules for occupational safety, and be very careful.
WARNING
• The Floodlight is designed entirely for rm mounting.
• Before connecting to the 220–240 V~ make sure that the connecting
wire is not under voltage. This operation can be carried out only by
an authorized person.
• Respect a minimum distance of 1 m between the appliance and the
object or surface which you wish to lighten.
• If you place the Floodlight below the roof, keep the minimum 0.2
m distance measured from the upside of the Floodlight to the
bottom of the roof.
• When using the Floodlight on a ammable surface, observe the
above instructions.
• The Floodlight may only be connected to electrical mains with
installation and protection that is in line with valid regulations
and standards.
min. 1 m
200 mm
min. 90˚
max. 50˚
