RS130 - RD160
SFP Connection Guide
1. Remove the protective caps
from the modules and
optical cable.
2. Insert the module into the
port on the RS130.
3. Insert the module into the
port on the RD160.
4. Connect the two modules with the optical cable.
※ Press firmly until you hear a click.
RS130 RD160
RD160
RS130
Components
11
SFP AUDIO IN
USB 3.0 FIBER
2
2
SFP Modules
(2ea)
Fiber
Optic Cable
Press the selection buttons on the far left and set the input to SFP.
From the OUTPUT options, select .
USB 3.0 FIBER
RD160 Configuration
5. On the RS130 screen,
tap the at the top right to enter the In/Out Settings.
9.
RS130 Configuration
second icon
6.
7. When the SFP Connection window appears, choose .
8. Confirm that the USB 3.0 FIBER option has changed to RD160-DAC.
RD160-DAC
INPUT
