Side 1/16

UMCWBD-L

Wideband UHF Diversity Antenna Multicoupler

INSTRUCTION MANUAL

Rio Rancho, NM, USA

www.lectrosonics.com

Fill in for your records:

Serial Number:

Purchase Date:

• Four slots for up to 16 audio

channels in 1RU

• Use with DCR822, DSR, DSR4,

UCR411 and SR units

• 11-18 VDC

• High quality RF distro covers

Blocks 470-26, Bands A1, B1, C1

UMCWBD-L

LECTROSONICS, INC.2

This product meets the CE Compliance Standards - EN55022 and EN50082-1:1998. A copy of the

Declaration of Conformity may be requested from your dealer or by contacting the factory directly:

Lectrosonics, Inc.

Marketing Department

581 Laser Rd. NE, Rio Rancho, NM 87124 USA

tel: 505-892-4501 fax: 505-892-6243

e-mail: marketing@lectrosonics.com

UHF Diversity Multicoupler

Rio Rancho, NM 3

Table of Contents

General Technical Description 4 ..............................................................................................................................................................

RF/Power Distribution Module Block Diagram 4 ..................................................................................................................................

Antenna Input 5 ......................................................................................................................................................................................

Power Supply 5 .......................................................................................................................................................................................

Assembly and Installation 6 ......................................................................................................................................................................

Installing the Receivers 6 .......................................................................................................................................................................

Installing the Wire Cover 7 .....................................................................................................................................................................

Installing the Assembled Unit..............................................................................................................................................................7

Antenna Types and Bandwidth 8 ..............................................................................................................................................................

Antenna Use and Placement 9 .................................................................................................................................................................

Accessories 10 ..........................................................................................................................................................................................

Specications 10 .......................................................................................................................................................................................

Service and Repair 11 ...............................................................................................................................................................................

Returning Units for Repair 11 .................................................................................................................................................................
