Lexon Mino+ L Bruksanvisning
Les nedenfor 📖 manual på norsk for Lexon Mino+ L (5 sider) i kategorien Radio. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/5
Design by Manuela Simonelli & Andrea Quaglio
LA129
25
4
3
6
1
(1) Speaker
(2) Microphone (Hands free phone call)
(3) Multi-Function Button (MFB button)
(4) USB type-C port
(5) Light indicator
(6) Wireless charging receiver
CHARGING
• Charge with USB cable
1. Plug the provided USB Type-C cable into the charging port of Mino+ L.
2. Plug the USB end of the cable into any computer or any DC 5V-1A power supply charger.
• Charge with Wireless Charger
Mino+ L has a built-in wireless charging receiver. You can charge the battery by using a wireless charger.
1. Place Mino+ L at the center of the wireless charger.
2. Disconnect the device once the battery has been fully charged
PAIRING / CONNECTING
Bluetooth® pairing
• Pair 1 MINO+ L
1. Turn on Mino+ L by pressing the “MFB” button for few seconds.
2. When the speaker is in pairing mode, it will emit a sound as notification and the Blue light indicator will start flashing rapidly.
3. Go into the Bluetooth® settings of your smartphone and make sure to switch on the Bluetooth® mode.
4. Scroll to Other or new Devices and look for your new Bluetooth® speaker’s “LEXON MINO+ L”.
5. Once it appears, tap it to connect. Your speaker will emit a confirmation sound as soon as it is paired.
Note: Once paired and connected, the Bluetooth® speaker will be automatically connected to your device whenever you turn the speaker
on again, provided the device is in range.
• Pair 2 MINO+ L (with the True Wireless Stereo technology)
1. Turn on both Mino+ L by pressing the “MFB” button for few seconds.
2. Before connecting both speakers devices with your smartphone, make sure to double press the “MFB” button of one Mino+ L until
hearing a continuous “du-du-du” sound. This Mino+ L will serve as the host device and it will actively search for the second Mino+ L.
A sound will confirm that both Mino+ L are successfully paired. The “LEXON MINO+ L” can automatically be paired together thanks to
the TWS technology.
3. Turn on the Bluetooth® of your smartphone, search for Bluetooth® speaker’s “LEXON MINO+ L”
4. Once it appears, tap it to connect. Your speaker will emit a confirmation sound as soon as it is paired.
Note: Once paired and connected, the Bluetooth® speaker will be automatically connected to your device whenever you turn the speaker
on again, provided the device is in range.
Light status indicator
If the indicator light does not work as described above, unplug the charger from MINO+ L and reconnect it.
Bluetooth® Hands-Free Operations
Answer/Hang up a call: Press the “MFB” button once.
Reject a call: Long press the “MFB” button.
Selfie control function
1) Make sure that your “LEXON MINO+ L” is paired with your smartphone.
2) Open the native camera of your smartphone and position your phone on a stable surface.
3) Ensure that your speaker is in range and press the “MFB” button to take a picture.
How to pair with another phone
1) To pair your speaker with another phone, make sure that your Bluetooth® speaker is ON and short press the “MFB” button twice.
2) To disconnect or forget “LEXON MINO+ L” directly from your smartphone's Bluetooth® settings first.
3) Then, perform a new pairing procedure with another smartphone.
SAFETY PRECAUTIONS:
Read all the instructions before using the device:
1. Protect the speaker from near heat sources such as radiators, heaters, air ducts, sunlight.
2. Avoid contact with other liquids: keep away from corrosive liquids.
3. Do not hit the product severely, or insert any conductive objects into the speaker, or charging port.
4. Do not repair the speaker by yourself; seek for professional service.
5. Avoid impacts.
6. Do not expose Mino+ L to water during charging, as this could permanently damage the speaker or power source.
PRODUCT SPECIFICATIONS:
Material: Aluminium/ABS
Weight: 0.54 lb / 245 g
Dimensions: Ø3.6 x 1.18"/ Ø9.2 x 3 cm
Water resistance: IPX4 - protects against everyday splashes and spills
Speaker power: 5W
Bluetooth® version: 5.1
Bluetooth® range: 10m
Battery voltage: 3.7V
Frequency range: 2402M-2480MHZ
Max. Power output: +4dBm
Normal usage time: 5h
Input port: DC 5V-1A
Battery type: Li-polymer
Battery capacity: 900 mAh
Charging system: USB Type-C or Supports wireless charging
Charging time (USB Type-C): approx. 2.5h
Wireless input: 5W
Charging time (wirelessly): approx. 3h
Operating temperature: -10°C – +50°C
International warranty: 1 year
Operation mode Light (5)
Power supply Steady Red light
Power On (Long press MFB button) Flashing Blue light and emits a sound
Power Off (Long press MFB Button) Emits a sound
Enter in pairing mode
Bluetooth® device connected with phone
Playing Music
Blue light flashing quickly
Steady Blue light and emits a sound
Blue light flashing slowly
Produkspesifikasjoner
| Merke: | Lexon |
| Kategori: | Radio |
| Modell: | Mino+ L |
