Side 1/20
Case Components
機殼部品介紹/ / / / Composants du boîtier Gehäusekomponenten Componentes de la caja ケース部品
IO ports: 1 x Hd AUDIO / Microphone Combo Jack, 2 x USB 3.0, 1 x USB 3.1 Type C, Reset Button, Power Button
Removable fan bracket, Supporting 120 mm fan x 3 or 140 mm fan x 2 or 360 mm radiator x 1 or 280 mm radiator x 1
INCL FAN 140 mm fan x 1 (200~1800 RPM / 81.30 CFM / 2.40 mm H2O), Supporting 120 mm fan x 1
Water Cooling Mode: Supporting 120 mm fan x 2 or 2.5” SSD x 2
Air Cooling Mode: Supporting 240 mm radiator x 1 or 120 mm fan x 2 or 140 mm fan x 2 or 2.5” SSD x 2
Removable fan bracket, Supporting 120 mm fan x 3 or 140 mm fan x 2 or 160 mm fan x 2 or
360 mm radiator x 1 or 280 mm radiator x 1
Supporting 2.5” SSD x 2
LANCOOL 216: INCL FAN 160 mm fan x 2 (500~1680 RPM / 118.85 CFM / 3.10 mm H2O)
LANCOOL 216 RGB: INCL FAN 160 mm ARGB fan x 2 (500~1680 RPM / 118.85 CFM / 3.10 mm H2O)
Removable HDD cage: Supporting 3.5” HDD x 2 + 2.5” SSD x 2
PSU tray, Supporting ATX PSU x 1 (Removable dust filter in bottom)
Reversible PCIE Slots
Controller tray
LANCOOL 216: None
LANCOOL 216 RGB: ARGB/FAN Hub (Sync Motherboard PWM Fan Header x6 / 5V ARGB Header x4)
- 1 -
Hardware List
零件部品⼀覽表 / Liste du matériel / Hardwareliste / Lista de hardware / ハードウェアリスト
Thumb screws
for rear fan bracket
Screws
for PSU mounting
Screws
for motherboard/
2.5"SSD mounting
Screws
for fan mounting
Stand-off bolt
(spare parts)
for motherboard mount
Tool
for stand-off bolt
Screws
(spare parts)
Screws
for air cooling duct
optimization baffle mount
Stand-off bolt
for Graphics card bracket
mount
Screws
for 3.5" HDD mount
Screws
for 2.5" SSD mount
Anti-vibration rings
for 2.5" SSD mount
Screws
for water cooling
mount
Screws
for fan mounting
Cable ties
for cable
management
Seal Plate to optimize
airflow
Exceeded quantity are spare parts.
多餘的零件數量是備品.
Les pièces supplémentaires sont des pièces de rechange.
Zusätzliche Teile können als Ersatzteile verwendet werden.
Exceeded quantity are spare parts.
Rear fan bracket
- 2 -
Rubber pad
(spare parts)
Remove the Top Cover and Front Panel
卸下上蓋及前⾯板 / Retirer le capot supérieur et le
panneau avant / Entfernen Sie die obere Abdeckung und
die Frontplatte / Retire la cubierta superior y el panel
frontal /トップカバーとフロントパネルを取り外す
Remove the Side Panel
卸下側板 / Retirer le panneau latéral / Entfernen Sie die Seitenwand / Retire el panel lateral/サイドパネルを取り外す
⼀般裝配時，不需拆卸此側板。
No need to remove the bottom side panel
while doing installation at the main chamber.
撕掉玻璃兩⾯的保護膜。
Peel off the protective film on both sides.
沒有要換 I/O及⾵扇無須拆下前⾯ 板。
No need to remove the front pa nel,
unless replacin g the I/O and the fans.
- 3 -
2
1
