INSTALLATION INSTRUCTIONS FOR PART 99-7339
APPLICATIONS
HYUNDAI GENESIS COUPE 2.0
2010-UP
KIT FEATURES
• ISO Head Unit Provision with Pocket
• Painted to match factory finish
99-7339B=Black 99-7339S=Silver
A) Trim Panel B) ISO Brackets C) Pocket D) (6) PC-7503 Panel Clips E) (4) 3/8” Phillips Screws
KIT COMPONENTS
A B C D
E
TOOLS REQUIRED:
Small Flat Blade Screwdriver • Phillips Screwdriver
Panel Removal Tool • Socket Wrench
1-800-221-0932
© COPYRIGHT 2007-2010 METRA ELECTRONICS CORPORATION
www.metraonline.com
99-7339B
99-7339S
METRA. THE WORLD’S BEST KITS.™
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Wiring Harness:
• 70-7303 - Kia/Hyundai Harness 2009 -up
Antenna Adapter:
• 40-KI11 - Kia/Hyundai Antenna Adapter 2007-up
Dash Disassembly
- Hyundai Genesis Coupe 2010-up . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
1
Kit Preparation
- Hyundai Genesis Coupe 2010-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Kit Assembly
- ISO DIN Head Unit Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
TABLE OF CONTENTS
99-7339
*Note:
Refer also to the instructions included with the aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
towa a better tomorrord w.
Metra recommends MECP
certified technicians
99-7339 DASH DISASSEMBLY
HYUNDAI GENESIS COUPE 2010-UP
A
B
C
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the shifter trim
panel. (
Figure A)
2
Unclip and remove the radio/climate
control trim panel.
(Figure B)
3
Unclip and remove the display trim
panel above radio.
(Figure C)
4
Remove (4) Phillips screws securing
the radio.
5
Remove (4) Phillips screws securing
the climate control to the factory trim
panel.
6
