Side 1/8
METRA. THE WORLD’S BEST KITS.™
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
APPLICATIONS
1-800-221-0932 metraonline.com
INSTALLATION INSTRUCTIONS FOR PART 99-7345B
WIRING & ANTENNA CONNECTIONS (Sold Separately)
Wiring Harness:
• 70-7304 - Hyundai/Kia 2010-up
Antenna Adapter:
• Not Required
Panel Removal Tool • Phillips Screwdriver • Socket Wrench
TOOLS REQUIRED
B C D
E
A
• A) Brackets • B) Trim Panel • C) Pocket • D) (3) #8 x 3/8” Pan Head Phillips Screws
• E) (4) #8 x 3/8” Truss Head Phillips Screws
KIT FEATURES
KIT COMPONENTS
• ISO DIN head unit provision with pocket
• Painted matte black to match factory finish
Table of Contents
Dash Disassembly
– Kia Optima 2011-up 3-4
Kit Assembly
– Vent transfer 5
– ISO DIN head unit provision with pocket 6
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better tomorrow.
Metra recommends MECP
certified technicians
99-7345B
Caution
Metra recommends disconnecting the negative battery terminal before beginning any
installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
*NOTE: Refer also to the instructions included with the aftermarket radio.
1. Unsnap and remove trim from around
top center to passenger side dash.
(Figure A)
2. Unsnap panel from outside edge of
driver’s side dash. (Figure B)
3. Remove two screws from knee panel
and pull top of panel back so it doesn’t
overlap the instrument cluster.
(Figure C)
4. Remove two screws from the driver’s
side vent trim and remove. (Figure D)
Continued on next page
Dash Disassembly
99-7345B
(Figure B)
(Figure A)
(Figure C)
(Figure D)
