Metra. The World’s Best Kits.® MetraOnline.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 6/4/24 INSTJP-1019
I N S TA L L AT I O N I N S T R U C T I O N S
JP-1019
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
PRODUCT FEATURES
• Designed to adapt the factory
4" with up to a 6"-6.75" speaker
with a tweeter option
• Retains the OE dome light
• Speaker depth: 4"
• Mounting plate/cutting template
included
• Hardware included
• Harness included
WHAT’S IN THE BOX
• A) Replacement Grilles • B) Mounting Plate / Template • C) Speaker Harness
Not Shown: (10) Coarse Thread Screws, (10) M4 Socket Head Screws, (1) Roll 1/4" Foam Tape
TOOLS REQUIRED
• 5/64 Drill Bit
• 3/16 Allen Wrench
• 10mm Socket Wrench
• T-15 Torx
• T-30 Torx
• M3 Allen Key
• Phillips Bit
• Oscillating Saw or
other Cutting Device
TABLE OF CONTENTS
Soundbar Removal................................................2
Soundbar Disassembly...................................... 3-4
Cutting Guide .........................................................5
Speaker Installation...............................................6
Dome Light Installation......................................... 7
Replacement Grille Installation............................8
Mounting Specifications........................................9
Jeep Wrangler (JL) 2024-Up
Jeep Gladiator (JT) 2024-Up
Rear Soundbar Speaker Adapter Plates
Visit for more detailed information about the
MetraOnline.com
product and up-to-date vehicle specific applications
B C
386.257.1187
|
MetraOnline.com
2
SOUNDBAR REMOVAL
NOTE: It is highly recommended that the
soundbar be removed for install of this
speaker adapter kit. (Figure A)
1. Remove all panels along the top trim of
the interior of the vehicle to gain access
to the soundbar mounts.
2. Remove the (6) 10mm bolts that are
securing the soundbar in place.
3. Unplug the harness and remove the
soundbar from the vehicle.
Continue to Soundbar Disassembly
Figure A
REV. 6/4/24 INSTJP-1019 3
SOUNDBAR DISASSEMBLY
1. Remove (5) 3/16” screws holding the
factory grille in place. (Figure A)
2. Disconnect the harness to the attached
map light, and remove the factory grille
panel. Put grille aside until time for
reinstall. (Figure B)
3. Remove the (7) T-15 screws from the
speakers in the sound bar and remove
the speakers. (Figure C)
4. Remove the (5) T-30 screws holding the
port assembly in place, and remove the
port assembly. (Figure D)
Figure C
Figure B Figure D
Figure A
