Condenser miniature microphone with
Cardioid polar pattern
The M 300 is a compact condenser microphone in studio quality. The
frequency response of the transmission factor is practically linear for a
wide range of sound incidence and has a smooth treble boost rising to
about 3 dB between 6 and 10 kHz. The miniature microphone is well suited
for vocal and instrumental soloists. lt permits a lifelike recording also at
various sound incidence, e.g. announcer in synchronous studios, speaker,
blower.
The M 300 is designed for studio applications in radio, television
broadcasting and films for live performance and recording of instruments,
vocals and speech and sound reinforcement in the professional and
semiprofessional market also under adverse acoustic conditions, e.g. in
churches.
A new low-noise integrated hybrid circuit and the transformerless circuit
design guarantee an extremely wide dynamic range by a low equivalent
loudness level and a high reliability in operation.
RFI susceptibility is very low.
The microphone is powered by a 3-pin XLR connector with the C 70
microphone cable. The power supply is provided by 48 V phantom
powering, which is internationally standardized as P 48 in DIN 45596 and
IEC 268-15. A two-channel powering is possible with the N 200 power
supply.
The finish of the miniature microphone is dark bronze.
M 300
M I C R OT E C H G E F E L L
F Ü R S T U D I O - U N D M E S S T E C H N I K
K O N D E N S A T O R M I K R O F O N E
SEIT 1928
MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 ( 36649 / 882 11- - 0)
INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de
Delivery
Microphone M 300 in wooden case L x B x H
Order-No. 211101
195 x 68 x 43 mm
dark bronze
Windscreen Order-No.
, black Order-No.
satin nickel Order-No.
, Order-No.
, Order-No.
Table stand Order-No.
Order-No.
Order-No.
Order-No.
Order-No.
, anthrazit
600018
21 mm 202307
202342
Double mount, 212332
Gooseneck, black 202324
Power supply 202101
202212
, Ø ,
202328
, 212304
202401
dunkel bronze
dunkel bronze
Popscreen
Microphone holder
Elastic suspension dark bronze
Elastic suspension dark bronze
Connection cable
W 20
PO 70
MH 64
EA 20
N 200
C 70
EH 93
TS 64
TD 93
ME 90
Accessories, optional
MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 ( 36649 / 882 11- - 0)
INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de
110°
90°
XY-arrangement
ORTF-arrangement
1 kHz 1 kHz 1 kHz
500 Hz 4 kHz 16 kHz
250 Hz 2 kHz 8 kHz
50
10
dB
-10
-30
0
-20
100 200 500 2k1k 5k 10k Hz 20k
0°
180°
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
0°
0
-10
-20
dB
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
0°
0
-10
-20
dB
30°
60°
90°
120°
150°
180°
210°
240°
270°
300°
330°
0°
0
-10
-20
dB
Cardioid
Pressure gradient transducer
40 … 18000 Hz
12 mV/Pa
100 Ω
26 dB
16 dB - A
68 dB
78 dB
147 dB
131 dB
3,3 mA
126 g
130 mm x 21 mm
3-pin XLR connector
goldplated contacts
Polar pattern
Acoustical operating principle
Frequency range
Sensitivity at 1 kHz
CCIR 468-4
DIN EN 60 651
CCIR-weighted
(re. 1 Pa at 1 kHz) A-weighted
Total dynamic range of microphone amplifier
Current consumtion (P 48, DIN 45596, IEC 268-15)
Output connector
Weight
Dimensions (L x )∅
Specifications M 300
Condenser studio microphone with cardioid polar pattern
Output impedance
Signal-to-noise-ratio
XY- and ORTF-stereo recording
Delivery
Mached pair of miniature microphone M 300 for XY and ORTF-stereo recording
in a wooden case L x B x H
211174
MH 64.1, double mount TD 93,
condenser
with microphone holder
Order-No.
195 x 68 x 43 mm
dark bronze
picture 2: ORTF-arrangementpicture 1: XY-arrangement
Certificate
Equivalent loudness level
due to inherent noise
Max. SPL for THD 0,5 %
Polar patterns M 300
Frequency responses M 300
