Side 1/1
Towel Bars
are die cast from highest
quality zinc alloy (zamac). Castings
are triple plated with a polished brass,
polished chrome or a powder coated
white finish.
q
5818PB
18” Towel Bar
Polished Brass Finish
Concealed Screw Mounting
¾” Round Bar
q 5818CH – 18” Towel Bar
Polished Chrome Finish
Concealed Screw Mounting
¾” Round Bar
q 5818W – 18” Towel Bar
White Finish
Concealed Screw Mounting
¾” Round Bar
q 5824PB – 24” Towel Bar
Polished Brass Finish
Concealed Screw Mounting
¾” Round Bar
q 5824CH – 24” Towel Bar
Polished Chrome Finish
Concealed Screw Mounting
¾” Round Bar
q 5824W – 24” Towel Bar
White Finish
Concealed Screw Mounting
¾” Round Bar
q 5830CH – 30” Towel Bar
Polished Chrome Finish
Concealed Screw Mounting
¾” Round Bar, Wholesale Packaging
Cleaning Instructions:
2 5 3 0 0 A L M O E N D R I V E N O R T H O L M S T ED, O H 4 4 0 7 0 ( 8 0 0 ) 3 2 1- 8 8 0 9
F AX: ( 8 0 0 ) 8 4 8 - - 6 6 3 6 I N T E RNATI O N A L : ( 4 4 0 ) 9 6 2 2000
-
2 7 2 6 C U S T O M E R S E R V I C E ( U S A ) : 8 0 0
-
882
-
011
6
1.
Position the mounting template on the wall in the d
esired location. Using a
level, align the template and tape it to the wall.
2. Place each mounting plate on the template with “UP” facing you.
3. One at a time, place each anchor screw through the mounting plate, centered
in each large hole. Using a Phillips screwdriver, turn the anchor screw while
applying pressure. Screw will self drill and tap into drywall. Do not over
tighten.
4. Only insert screw ½ to ¾ of the way into wall.
5. After all screws are installed, tear the template away from the wall
6. Tighten all 4 screws. Do not over tighten.
7. Assemble the Towel bar and posts.
8. While assembled, Position each end post with the setscrew down and place
over both mounting plates. Tighten the setscrew at the bottom of each base.
St
ock Number:
______________________Towel Bar
By CSI Bath Furnishings
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
18”,
24”
& 30
Towel Bar
5818, 5824 & 5830
Aspen Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
Copyright CSI Bath Furnishing Division of Moen 02/22/01
Literature #BA0967
Length 18" 24" 30"
Dim. "A" 21.00 33.0027.00
Dim. "B" 18.50 30.5024.50
Dim. "C" 17.00 29.0023.00
