SERRA
Quick guide
Thank you for choosing SERRA
for your Eurorack System.
Powering up
Turn off the power of your modular synthesizer.
Double check the power cord polarity. If you plug the module backwards you might
damage its electronic circuits.
If you flip over your SERRA, you will find the “RED” mark at the PCB power connector,
which must match the colored line on the ribbon cable.
Once you have checked all the connections, you can turn on your modular system.
If you notice any anomalies, turn your system off right away and check again your
connections.
1.
2.
3.
4.
REDRED
SERRA NANO Modules - València 2022 ©
NANO Modules - València 2022 ©
SERRA is an module.ADSR Envelope
An describes how a sound changes over time. Synthesizers use Envelope
envelopes to create shapes designed for making musical sounds. You can adjust the
envelope’s controls to tell it what kind of shape to make. It normally relates to the
amplitude (volume), but it may also involve elements such as filters (frequencies) or
pitch.
An Attack – Decay – Sustain – Release) means that it consists of 4 ADSR Envelope (
phases. These can be adjusted in time with its own sliders and external CV inputs.
SERRA is not only a classic ADSR envelope, it also includes some controls which
allow a to get the most of the voltage curves generated by it.deeper operation
More control
Thanks to its built-in Attenuverter & Offset controls, you can play with the
amplitude, polarity and voltage level of the output signal, making the module
extremely versatile for every use you could imagine.
Description
SERRA
time
ADSR ENVELOPE
voltage
A D S R
Fig.1 ADSR Envelope Signal Shape
Key Pressed Key Released
max. level
