Radial Engineering Ltd.
1845 Kingsway Ave, Port Coquitlam BC V3C 0H3
Tel: 604-942-1001 • Fax: 604-942-1010 • Email: info@radialeng.com
U s e r G u i d
CAB•LINK
CAUTION: Please read safety disclosure
statement on the inside cover before
connecting your Radial Cab-Link
Cab-Link Speaker Cabinet Combiner
Features 1 ..............................................................................
Making Connections 2-3 ........................................................
Line Output 4 ..........................................................................
Block Diagram 5 .....................................................................
Specications ......................................................................5
Warranty Back Cover .............................................................
Thank you for purchasing the Cab-Link, a rugged problem-
solver that allows you to connect a single amplier to two
speaker cabinets with ease. Before using the Cab-Link, please
take a moment to review this short manual for full details on
how to connect and utilize this handy device.
If you nd that you have any unanswered questions, please visit
the FAQ page on our website where we post questions from
other users as well as updates. If you require more information
still, please send us an email at info@radialeng.com and we
will do our best to respond promptly.
ALWAYS TURN YOUR AMPLIFIER OFF BEFORE
CONNECTING OR DISCONNECTING THE CAB-LINK.
It is your responsibility to conrm the Cab-Link is connected
properly before operating your amplier. If you are unsure
about connecting or operating the Cab-Link consult a
qualied technician or see your dealer. Damage caused by
improper operation is not covered under the warranty. See
the back cover for warranty details.
CAUTION - USE OF THE CAB-LINK WITH AMPLIFIERS
WITH BRIDGED OR BALANCED SPEAKER OUTPUTS
IS STRICTLY PROHIBITED.
These types of circuits, typically a type of a Class-D design,
are not suited for use with the Cab-Link. Using the Cab-Link
with them may cause an electrical shock and therefore
Radial Engineering Ltd. strictly prohibits use of the Cab-
Link with such ampliers. Please consult the amplier
manufacturer to ensure the power output section of your
amp is not designed this way.
CAUTION STATEMENT
Please read before connecting
your Radial Cab-Link
Radial Engineering Ltd. Cab-Link User Guide
1
FEATURES
1 2 3
4
5
6
1. FROM AMP SERIES: Connect your
amplier to this input when using in series
conguration.
2. FROM AMP PARALLEL: Connect your
amplier to this input when using in parallel
conguration.
3. SPEAKER A & B OUTPUTS: Connect to
the inputs of your two speaker cabinets.
4. LINE OUT: Additional output can feed
another amplier or effects device.
5. LEVELS: Adjusts the signal level of the
Line Out.
6. 14-GAUGE STEEL: Solid steel enclosure
ensures the Cab-Link will handle the most
rigorous touring environments.
