Acclaim™ 5 Series OutBack
Outdoor Rock Loudspeaker
and Rock Subwoofer
Installation Manual
2 Russound Acclaim OutBack Rock Speaker Installation Manual
INTRODUCTION
Introduction
Thank you for selecting an outdoor rock speaker from Russound. Like all
Russound speakers, they combine acoustic technology with durability and
will provide years of musical enjoyment.
These Rock Speakers are designed to look like natural outcroppings of rock
instead of bulky aluminum and plastic speakers that detract from nature’s
beauty. Russound Rock Speakers are a distinctive addition to your yard
and blend into any landscape for a convenient and practical outdoor audio
solution.
The realistic rock speakers are oered in three styles to match your landscape:
Gray Granite, Weathered Granite and Sandstone. These shapes and nishes
closely mimic rocks found in nature for a quality, believable look. The secret
to the realistic look of the rock speakers is in the way they are crafted. The cast
enclosure process produces more lifelike shapes and surfaces. This process is
more expensive, but the three-layer berglass and resin construction results
in an acoustically better speaker with low resonance for better sound. The
process also creates an environmentally stable and durable speaker housing.
The resulting Rock Speaker has a sturdy, waterproof cabinet tough enough
for use in all types of weather and environments. The enclosure is silicone
sealed and equipped with a water drain for the speaker opening. For added
convenience an attached security eyelet is provided to prevent the speaker
from getting ‘carried away.’
Each speaker has an 8” coaxial two-way or single-point stereo driver with a
polypropylene cone and fully painted aluminum grille.
With 10 – 125 watt power handling, Russound Rock Speakers t any outdoor
speaker necessities, for monaural or stereo applications.
Amplier Considerations
The Rock Speakers should be powered by an amplier that provides a
minimum of 10 watts per channel. An amplier that has both stereo and mono
capability is a plus, as you may want to use mono for large areas.
If you intend to use more than one pair of speakers at a time it’s important
to consider both the impedance of the speakers and the capabilities of the
amplier or receiver. Not all ampliers or receivers can safely operate two sets
of speakers at once.
4 Russound Acclaim OutBack Rock Speaker Installation Manual
Placement of Speaker Pairs
The best stereo imaging can be achieved by placing rock speakers no closer
than 20 feet next to one another. The sound propagation outward from the
face of the speaker is ideal within a 20 to 30 foot range. The rock speakers can
certainly cover larger areas but as the distance between adjacent speakers
increases, the stereo imaging starts to deteriorate. As the distance between
opposing speakers increases beyond the 20 to 30 foot range, the volume level
to cover the whole area can reach uncomfortably loud levels when the listener
moves closer to the speakers.
Large areas are better served by monaural audio instead of stereo. In most
outdoor environments, there is no ideal listening area to give stereo image or
separation.
Placement of a Subwoofer
As with the stereo speakers, a rock speaker can generally cover an area around
it of 20-30 feet (6-9 meters). Your Russound rock subwoofer is front-ring
but the bass sound is less directional than higher frequencies. As with stereo
speakers, using more rock speakers playing at a lower sound volume to cover
a larger area is better than having fewer speakers playing loudly as they can
tend to create too many "hot" spots where the sound is uncomfortably loud.
Keep in mind that placing a subwoofer near a wall or other solid phyiscal
boundary can augment the sound by approximately 3dB.
20 feet +/-
20 feet +/-
20 - 30 feet
20 - 30 feet
Rock speaker stereo imaging placement
PLACEMENT FOR STEREO IMAGING
