Side 1/11
CFexpress 4.0
Type A Memory Card
Quick Start Guide
© 2024 Wise Advanced Co., Ltd.
www.wise-advanced.com.tw
CFX4-A Series
CFX4-A512M2
512GB
1865MB/s
1750 MB/s
400 MB/s
CFexpress Type A
PCIe Gen 4 x1, NVMe 1.4
VPG400
TLC
20.0 x 28.0 x 2.8 mm
2 g
10˚F to 162˚F (-12˚C to 72˚C)
-13˚F to 185˚F (-25˚C to 85˚C)
English How to Use Wise CFexpress 4.0
Type A Memory Card
Before operating this media, please read this manual thoroughly, and retain it for future reference.
Components
Wise CFexpress 4.0 Type A Memory Card
Quick Start Guide
How to connect
Select the device compatible with the Wise CFexpress Card Reader.
Connect one end of the cable to the device and the other end to
the reader with the card insert.
Tech Specs
Model
Capacity1
Maximum Read2
Maximum Write2
Minimum Write2
Form Factor
Interface
Video Performance Guarantee:
NAND Flash
Size
Weight
Operating temperature
Storage temperature
1 Some of the listed storage capacity is used for formatting and other purposes and is not available
for data storage. 1GB = 1 billion bytes.
2 Speeds based on internal testing. Actual performance may vary.
Caution
Wise shall not be responsible for any damage to or loss of recorded data.
Recorded data may be damaged or lost in the following situations.
If you remove this media or turn off the power while formatting, reading or writing data.
If you use this media in locations subject to static electricity or electrical noise.
CFX4-A256M2
256GB
CFX4-A1024M2
1TB
When this media is not recognized with your product, turn the power off and on again or restart
the product after removing this media.
Connecting the Wise CFexpress cards to non-compatible devices may result in unexpected
interference or malfunction of both products.
Copyright law prohibits unauthorized use of recording.
Do not strike, bend, drop or wet this media.
Do not touch the terminal with your hand or any metal object.
Do not expose the unit to rain or moisture.
All Wise memory cards have a 2-year warranty. If you register your product here online, you can
extend it to 3 years at no additional charge: www.wise-advanced.com.tw/we.html
Any damage caused by customers through neglect or incorrect operation may result in the
warranty being void.
For more information, please visit www.wise-advanced.com.tw
Wise Advanced is an authorized licensee of the CFexpress™ trademark, which may be registered in
various jurisdictions. Information, products, and/or specifications are subject to change without
notice. The Wise logo is a trademark of Wise Advanced Co., Ltd.
Deutsch Wie Sie Ihre Wise CFexpress 4.0 Typ A
Speicherkarte nutzen
Bitte lesen Sie diese Anleitung vor der ersten Anwendung sorgfältig und bewahren Sie sie auf.
Lieferumfang
Wise CFexpress 4.0 Typ A Speicherkarte
Schnellstartanleitung
Anschluss
Wählen Sie das Gerät, das mit dem Wise CFexpress Kartenlesegerät kompatibel ist.
Verbinden Sie das eine Kabelende mit dem Gerät und das andere
mit dem Lesegerät mit der eingelegten Karte.
Technische Spezifikationen
Modell
Kapazität 1
Lesegeschwindigkeit
(max.) 2
Schreibgeschwindigkeit
(max.) 2
Schreibgeschwindigkeit
(min.) 2
Formfaktorr
Schnittstelle
Videoleistungsgarantie
CFX4-A512M2
512GB
1865MB/s
1750 MB/s
400 MB/s
CFexpress Type A
PCIe Gen 4 x1, NVMe 1.4
VPG400
CFX4-A256M2
256GB
CFX4-A1024M2
1TB
