Bebob AS2MICRO Bruksanvisning

Les nedenfor 📖 manual på norsk for Bebob AS2MICRO (2 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 5 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Side 1/2
bebob factory GmbH Höglwörtherstr. 350 Tel.: +49 89 27818282 – D-81379 München –
www.bebob.de
March 2020
Features
- . 2 Channel AMount simultaneous Li Ion Charger
AC Adapter. 16,8V 5.0A DC Dtap (male) Output
Powerbase Mode.
Charging
Never leave batteries unattended while charging
Plug the blue Dtap Plug of the S1micro in the blue Twist Dtap Socket of the Powerbase -A .micro
The S1micro led indicator show green when the charger is plugged in with no battery connected
The Channel Status indicator turns red when a battery is placed on the corresponding channel
and the charging process has begun
The Channel Status indicator turns back green when the battery is fully charged
AC Adapter S1MICRO
hYou can use your S1micro AC Adapter (Part of the Kit) as a 1 C annel Travel Quick
Charger
Plug the Blue Dtap in theTwist Dtap Socket on any bebob battery (but Bmount)
1 V The AC adapter delivers up to 5,0A under 6,8
AS2MICRO P -ortable simultaneous li ion
battery charger
User Manual
WE STRONGLY RECOMMEND THAT YOU
READ THIS INSTRUCTION BEFORE USING
YOUR BEBOB AS2MICRO CHARGER !
PLEASE KEEP THIS MANUAL FOR FUTURE
REFERENCE
bebob factory GmbH Höglwörtherstr. 350 Tel.: +49 89 27818282 – D-81379 München –
www.bebob.de
march 2020
Powerbase
f -A Plug of the S1micro from the Powerbase micro
Place one or two full batteries on the Powerbase
Battery Power will be available over the black twist Dtap Socket
Maximum Load depends on the batteries and limited to 10A
Safety instructions
t Only for professional use! Keep Charger out of reach of children and personnel tha has
not been instructed in the use!
U . se only with recommended batteries
Keep the charger dry and do not immerse in water.
Do not cover the charger under use
Do not keep in contact with any part of the body while the charger is in working status.
Do not use or store the charger in unstable, dusty or damp environments.
Remove the battery from the charger after the charging process is complete.
Do not attempt to open or repair the charger. Contact your dealer for help if it becomes
defective.
Handle with care! Do not throw! Do not drop!
Warranty
. The AS2micro is covered by a 2 years unconditional warranty on all parts
For warranty issues or if you have any additional questions, please contact the appropriate
bebob distributor listed at www.bebob.de.
S pecifications
Model
A S2micro
Mount
A micro
Channel
2 simultaneous
Charging current
16,8V 2.5A per Channel 5,0A global
AC In
90 264V/47 63Hz 100W- -
Weight AC Adaptor
0,365 Kg
Dimensions (WXHXD)
40 x 138x 60mm
Weight Powerbase
0,160 Kg
Dimensions (WXHXD)
96 66 45 x x mm
Batteries
bebob
Charging time
d epends on the battery capacity
Operating Temp. Range
- 10°C ~ + 35°C
