Revolution 6x6

6-in / 6-out USB audio interface / word clock / DAC / ADC

with USB OTG

Quick Start Guide

SOFTWARE REGISTRATION CODE

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat regis-

ters, stoves, or other apparatus that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other.

A grounding-type plug has two blades and a third grounding prong.

The wide blade or third prong is provided for your safety. If the pro-

vided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particular-

ly at plugs, convenience receptacles, and the point where they exit

from the apparatus. If the power cord becomes frayed, stop using

immediately.

11. Use only attachments/accessories specied by the manufacturer

12. Use only with a cart, stand, tripod, bracket or table specied by the

manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid in-

jury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for

long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is re-

quired when the apparatus has been damaged in any way, such as

power supply cord or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the apparatus has been ex-

posed to rain or moisture, does not operate normally, or has been

dropped.

15. This apparatus shall not be exposed to dripping or splashing, and

no object lled with liquids, such as vases, shall be placed on the

apparatus.

16. Note that this apparatus is not completely disconnected from the

AC mains service when the power switch is in the OFF position.

17. The mains plug or power inlet on the product is used as the discon-

nect device, so the disconnected device shall remain readily opera-

ble when reconnected.

18. Any changes or modications not expressly approved in this manu-

al could void your authority to operate this apparatus.

The lightning ash with an arrow-

head symbol within an equilateral

triangle is intended to alert the

user to the presence of uninsu-

lated “dangerous voltage” within

the product’s enclosure that may

be of sucient magnitude to

constitute a risk of electric shock

to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the product.

The Black Lion Audio Revolution 6x6 complies with all applicable

RoHS / WEEE European Union directives.

Do not attempt to service this unit yourself, as it will void your warran-

ty. Please check your unit carefully upon receipt and return to place

of purchase immediately if there are any problems with the product.

After that, the standard Black Lion Audio 3 YEAR warranty will apply

to defects in materials and workmanship.

U.S.A.

Should your Black Lion Audio product require service,

please contact the Black Lion Audio Service Department:

https://www.blacklionaudio.com/contact. You must obtain an RA #

(Return Authorization number) from us before shipping a unit back to

us. This RA # must be clearly written on the outside of the box.

Please safely pack the units…It is best to use the original packing

materials. Black Lion Audio cannot be responsible for any damag-

es incurred in shipping to us due to poor packaging. PLEASE PACK

CAREFULLY and FULLY INSURE THE SHIPMENT.

INTERNATIONAL

For service or warranty assistance, please contact the Black Lion Au-

dio distributor in your country through the dealer from whom you pur-

chased this product.

LIMITED 3 YEAR WARRANTY

Black Lion Audio’s Revolution 6x6 is warranted by Black Lion Audio to

be free from defects in materials and workmanship for the period of

THREE (3) YEARS to the original purchaser. In the event of such defects,

the product will be repaired without charge or, at our option, replaced

with a new one if delivered to Black Lion Audio prepaid, together with a

copy of the sales slip or other proof of purchase date. The warranty ex-

cludes problems due to normal wear, abuse, shipping damage or failure

to use the product in accordance with the specications.

All parts and labor are covered under this Limited Warranty. However,

if it is determined by Black Lion Audio that the device was damaged or

made defective through abuse, we reserve the right to charge the cus-

tomer for the cost of the repair.

Black Lion Audio shall not be liable for damages based upon inconve-

nience, loss of use of the product, loss of time, interrupted operation or

commercial loss or any other damages, whether incidental, consequen-

tial or otherwise. This warranty gives you specic legal rights, and you

may have other rights, which will vary from state to state.

This warranty is not transferable.

LET’S GET STARTED! GETTING TO KNOW THE REVOLUTION 6X6.

Windows users: Install the Revolution 6x6 Windows ASIO driver. This

installer was designed to be easy to use. Simply follow the on-screen in-

structions. You will be alerted that the installer has successfully nished

and it will prompt you to reboot your computer. Click “Finish” to automat-

ically restart your computer.

The ASIO drivers are available for download on the Black Lion Audio

website on the bottom of the Revolution 6x6 page.

MacOS users: The Revolution 6x6 is a class-compliant Core Audio de-

vice, so no installation is necessary. Simply connect your Revolution 6x6

to your computer to begin using it.

1. Turn the Mixer knob on the front panel of your Revolution 6x6 to the

12 o’clock position. This will allow you to hear both your inputs and

the playback from the computer.

2. Connect a pair of headphones to the Revolution 6x6 headphone out-

put and turn the Phones volume control to the 12 o‘clock position.

1. Go to www.blacklionaudio.com

2. Click on the “REGISTER PRODUCT” button on the upper right corner.

3. Click “Create an Account” and follow the on-screen instructions.

You’ll need to verify your email address once submitted.

4. Return to blacklionaudio.com and click on the “REGISTER PROD-

UCT” button on the upper right corner. Log in to your new account.

5. Click “Register a product” in the blue bar on the top left.

6. Enter serial number of the unit. It’s located on the bottom of the unit.

7. Enter software number. It’s located on the front cover of this man-

ual.

8. Click “Verify.” The following screen will contain your software codes

and download instructions.

1. Connect a microphone then speak into it while watching the input

meter in your DAW. Slowly turn the Revolution 6x6’s Input 1 Preamp

Gain knob clockwise to establish a suitable recording level.

2. Engage MONO button for input monitor summing.

3. Click the “Record“ button in your DAW to begin recording your rst

track!

Product registration and software download instructions Front Panel

Rear Panel

Connecting to a Computer (Mac & Windows)

Prepping for Playback

Recording

1. Inputs: XLR-Combo inputs for connecting microphones,

instruments, and line-level equipment. Use the center-balanced

1/4” connection in this jack for line-level and Hi-Z devices (electric

guitars and basses.)

2. Instrument Input Switches: This selects between unbalanced

instrument level and balanced line level for the 1/4” input on the

XLR-Combo inputs.

3. Preamp Gain: This knob controls gain on the preamplier.

4. Input LED: This LED indicates the levels coming into the interface.

Green=signal received; Red=clipping.

5. 48V Buttons: These buttons turn on 48V phantom power per chan-

nel.

6. Main Meter: This meters the analog input or output levels. When set

to Input Metering mode, signals hitting 0 dBFS are clipping. S/PDIF

connections are not metered unless in Standalone mode.

7. Monitor: This attenuates the analog output level.

1. 5V Power Connector: USB-C Connection for power only.

2. Power Switch: Turns the unit off or on.

3. USB-C to Computer: Connect your computer here.

4. OTG Connector: Connect mobile devices that support USB OTG (On

the Go) here.

5. S/PDIF Output: Use this to output two channels of digital audio to

another device.

6. S/PDIF Input: Connect S/PDIF digital outputs from devices here.

7. Word Clock Output: Use this to use the Revolution 6x6 as a primary

clock for your other devices.

8. Word Clock Input: Use this to sync Revolution 6x6 to your primary

clock when in standalone mode.

9. Monitor Output: Main outputs. Connect your monitor speakers here.

A note on the power supply: While Revolution 6x6 can be run over

bus power via the USB connection, we recommend using the included

power supply to use the headphones at full volume or standalone mode.

When connecting to AC power using the included power supply, use one

of the included USB cables for power and the other for your computer

connection.

A note on USB OTG: USB OTG (On-the-go) allows you to connect a mo-

bile USB device to the Revolution 6x6 and send audio to and from the

device. Sample from your phone to your laptop, or livestream a laptop

session from your phone!

8. USB Status: This LED indicates the status of USB connectivity:

ĥ Blinking Red: Unit is powered on; no secure connection to host

via USB or OTG (when not in Standalone mode).

ĥ Solid Red: OTG Source is connected and secure, but there is no

USB source securely connected.

ĥ Solid Yellow: USB source is connected and has a secure connec-

tion to the host AND there is a secure OTG connection as well.

ĥ Solid Green: USB source is connected and has a secure connec-

tion to host.

9. Direct Mixer: This knob is a direct mixer for monitoring inputs in re-

al-time. Turn left for inputs, and turn right for playback.

10. Headphone Volume: This controls the headphone volume level.

11. Headphone Output: Connect your headphones here.

12. Mono HP: Engaging this switch performs mono summing of the

headphone outputs. For monitoring stereo inputs, make sure this

button is disengaged. This button only effects input monitor, and

not playback monitoring.

13. Sample Rate: Press and hold to engage Standalone mode to use the

Revolution 6x6 without a computer as a primary clock, DAC, or ADC.

Press to cycle through available options. BNC and S/PDIF are clock

input sources for Standalone mode.

14. Input Meter: Toggles the Main Meter between displaying analog

input or output levels. Lit=input metering; unlit=output metering.

Connect microphone here.

Connect headphones here.

987

61 2

13 12

1 2 3 4 5 7 96 8

Produkspesifikasjoner

Merke:	Black Lion Audio
Kategori:	Ikke kategorisert
Modell:	Revolution 6x6

Trenger du hjelp?

Hvis du trenger hjelp med Black Lion Audio Revolution 6x6 still et spørsmål nedenfor, og andre brukere vil svare deg

Ditt navn*

Din e-post*

Skriv spørsmålet ditt her

Ikke kategorisert Black Lion Audio Manualer

Black Lion Audio Revolution EXP Bruksanvisning

28 Oktober 2024

Black Lion Audio SEVENTEEN 500 Bruksanvisning

28 Oktober 2024

Black Lion Audio Revolution 6x6 Bruksanvisning

28 Oktober 2024

Black Lion Audio Revolution 2x2 Bruksanvisning

27 Oktober 2024

Black Lion Audio PG-X Type C Bruksanvisning

16 Oktober 2024

Black Lion Audio PBR TT Bruksanvisning

16 Oktober 2024

Black Lion Audio PBR TRS3 Bruksanvisning

16 Oktober 2024

Black Lion Audio PG-P Type C Bruksanvisning

16 Oktober 2024

Ikke kategorisert Manualer

Nyeste Ikke kategorisert Manualer

Daewoo Cyclone Essential FLR00038 Bruksanvisning

28 Oktober 2024

IFM SU6631 Bruksanvisning

28 Oktober 2024

IFM SU7031 Bruksanvisning

28 Oktober 2024

IFM SV8051 Bruksanvisning

28 Oktober 2024

Daewoo AVS1464 Bruksanvisning

28 Oktober 2024

IFM PT5300 Bruksanvisning

28 Oktober 2024

IFM KTE301 Bruksanvisning

28 Oktober 2024

IFM OVP810 Bruksanvisning

28 Oktober 2024

IFM SF0516 Bruksanvisning

28 Oktober 2024

IFM TSM701 Bruksanvisning

28 Oktober 2024
