Side 1/5
SPECIFICATION:
MODEL NO. : IWD- 1020C
POWER CONSUMPTION : Hot –450W
Cold –120W
RATED VOLTAGE : 230Va.c. 60Hz
IMPORTANT SAFEGUARDS:
When using electrical appliances, basic safety precautions should always be followed, including the
following:
1. Read all instructions thoroughly.
2. Before using the Water Dispenser, check if the voltage indicated corresponds with the convenience
outlet (230Va.c.).
3. Do not use two-way socket with another appliance.
4. Do not use any appliance with a damaged cord or plug. If the cord is damaged, it must be replaced
with the same type and size of a qualied person or bring the unit to the manufacturer or to the
nearest Imarex Authorized Service Center to avoid hazard.
5. To avoid a hazard due to instability of the appliance, it must be xed in accordance with the
instructions.
6. Do not place the Water Dispenser near gas stove, electric burner or heated oven.
7. Children should be supervised to ensure that they do not play with the appliance.
8. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliances by a person responsible for their safety.
9. Keep the water dispenser in a dry and cool place and avoid direct sunlight. Rearward of the
machine should be at least 20cm far from the wall. Never put the machine on the paper or foam,
which may cause unstable condition, such as store water or cause creepage. Never put anything
ammable beside this machine.
10. To avoid damage, do not plug the power cord or turn on the heating switch until 3 minutes after
you put the lled water gallon.
11. This water dispenser must be used with third-prong grounding plug and creepage protection switch.
If two at plugs will use, the grounding wire must be properly grounded before use.
12. In case the unit will not use for a long time, turn o the switch and pull the plug out from the socket
then drain the remaining water through drain hole.
13. Never use organic liquid to clean the machine. Splashing of water to the body is strictly prohibited.
14. You should use the ON/OFF switch to turn on or o the unit. It is prohibited to turn on or o the unit
through plugging or unplugging the power cord. Never extend the length of the power supply cord
to avoid re.
15. Never turn the machine upside down or lean it more than 45°.
16. Do not adjust the thermostat of the unit by yourself.
17. Power cord or other parts of the unit must be replaced by authorized service center personnel.
18. The cooling time of the unit might take longer when the environment temperature is higher than
the normal.
19. Save this instruction for future reference.
DESCRIPTION OF PARTS:
CIRCUIT
FRONT
REAR
NUMBER
PART NAME
NUMBER
PART NAME
1
Gallon
Supporter
7
Cabinet
2
Top Cover
8
Cooling
Switch
3
Indicator Light
9
Heating
Switch
4
Hot Water Tap
10
Power Cord
5
Normal Water
Tap
11
Drain Hole
6
Cold Water
Tap
12
Condenser
Produkspesifikasjoner
| Merke: | Imarflex |
| Kategori: | Vanndispenser |
| Modell: | IWD-1020C |
