Imarflex IWD-1160UV Bruksanvisning
Imarflex
Vanndispenser
IWD-1160UV
Les nedenfor 📖 manual på norsk for Imarflex IWD-1160UV (4 sider) i kategorien Vanndispenser. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/4
SPECIFICATION:
MODEL NO. : IWD-1160S
POWER CONSUMPTION : Hot –500W
Cold W –85
RATED VOLTAGE : 230Va.c. 60Hz
BOX DIMENSION : 355*390*1115mm
UNIT DIMENSION : 310*340*1035mm
GROSS WEIGHT : 17.3 kg.
NET WEIGHT : 15.2 kg.
IMPORTANT SAFEGUARDS:
When using electrical appliances, basic safety precautions should always be followed, including the
following:
1. Read all instructions thoroughly.
2. Before using the Water Dispenser, check if the voltage indicated corresponds with the convenience
outlet (230Va.c.).
3. Do not use two-way socket with another appliance.
4. Do not use any appliance with a damaged cord or plug. If the cord is damaged, it must be replaced
with the same type and size of a qualied person or bring the unit to the manufacturer or to the
nearest Imarex Authorized Service Center to avoid hazard.
5. To avoid a hazard due to instability of the appliance, it must be xed in accordance with the
instructions.
6. Do not place the Water Dispenser near gas stove, electric burner or heated oven.
7. Children should be supervised to ensure that they do not play with the appliance.
8. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliances by a person responsible for their safety.
9. Keep the water dispenser in a dry and cool place and avoid direct sunlight. Rearward of the
machine should be at least 20cm far from the wall. Never put the machine on the paper or foam,
which may cause unstable condition, such as store water or cause creepage. Never put anything
ammable beside this machine.
10. To avoid damage, do not plug the power cord or turn on the heating switch until 3 minutes after
you put the lled water gallon.
11. This water dispenser must be used with third-prong grounding plug and creepage protection switch.
If two at plugs will use, the grounding wire must be properly grounded before use.
12. In case the unit will not use for a long time, turn o the switch and pull the plug out from the socket
then drain the remaining water through drain hole.
13. Never use organic liquid to clean the machine. Splashing of water to the body is strictly prohibited.
14. You should use the ON/OFF switch to turn on or o the unit. It is prohibited to turn on or o the unit
through plugging or unplugging the power cord. Never extend the length of the power supply cord
to avoid re.
15. Never turn the machine upside down or lean it more than 45°.
16. Do not adjust the thermostat of the unit by yourself.
17. Power cord or other parts of the unit must be replaced by authorized service center personnel.
18. The cooling time of the unit might take longer when the environment temperature is higher than the
normal.
19. Save this instruction for future reference.
DESCRIPTION OF PARTS:
NO.
DESCRIPTION
1
Hot Water Button
2
Room Temp Water Button
3
Cold Water Button
4
Cooling Light Indicator
5
UV / Rell Tank Light Indicator
6
Boiling Light Indicator
7
Water Tap
8
Removable Water Collector
9
Reset Button
10
Cabinet Door
11
Water Pump
12
Water Gallon
13
Hot Power Switch
14
Cold Power Switch
15
Condenser
16
Power Cord
17
Drain Valve
HOW TO USE:
1. Tear the label from the water gallon.
2. Put the water pump rod inside the gallon and place slowly inside the unit.
3. Insert the plug to the socket and wait for about 5 minutes before you turn ON the power switch.
4. Press the Hot, Cold and Room Temp Water button. Once, there is water ows out in every water
tap you may now turn ON the hot & cold power switch located at the back portion of the unit. The
indicator lights up accordingly once the machine works.
5. The UV Function has a one-hour interval. For the rst hour, there will be a Steady Light Indicator,
showing that the UV is working. For the second hour, the UV light indicator will turn o indicating
that the UV function is o. This cycle will be continuous. UV light indicator lights up indicating that
the UV is working.
6. The rell water light indicator will be ashing once the water gallon needs to be rell . ed
For Initial Use:
1. Clean the unit.
a. Put the water pump rod inside the gallon and place slowly inside the unit.
b. Press the cold, room temp and hot tap until the water ows out of the faucet for about 20
minutes.
c. Pull o the water pump rod into the gallon and turn on the drain valve to empty the water inside
the unit.
