Side 1/21
ASI Manual 294
Revision 2.2
Feb, 2022
All material in this publication is subject to change without notice and its copyright totally
belongs to Suzhou ZWO CO.,LTD.
ASI294 Manual
2
Table of Contents
ASI294 Manual ............................................................................................................................... 1
1. Instruction ................................................................................................................................. 3
2. What's in the box? ..................................................................................................................... 4
3. Camera technical specications ................................................................................................ 5
4. QE Graph & Read Noise ........................................................................................................... 6
5. Getting to know your camera ...................................................................................................... 11
5.1 External View .................................................................................................................... 11
5.2 Power consumption ........................................................................................................... 12
5.3 DDR Buffer ....................................................................................................................... 13
5.4 Cooling system .................................................................................................................. 13
5.5 Back focus distance ........................................................................................................... 13
5.6 Protect Window ................................................................................................................. 14
5.7 Analog to Digital Converter (ADC) .................................................................................. 14
5.8 Binning .............................................................................................................................. 15
6. How to use your camera ......................................................................................................... 15
7. Cleaning .................................................................................................................................. 18
8. Mechanical drawing ................................................................................................................ 20
9. Servicing ................................................................................................................................. 21
10.Warranty .................................................................................................................................... 21
ASI294 Manual
3
1. Instruction
Congratulations and thank you for buying one of our ASI Cameras This manual will give you a
brief introduction to your ASI camera. Please take the time to read it thoroughly and if you have
any other questions, please feel free to contact us at info@zwoptical.com.
Welcome to join ZWO FB and User Forum below!
Facebook : https://www.facebook.com/ZwoDesignAstronomyCameras
User Forum: https://bbs.astronomy-imaging-camera.com/
ASI294 Camera is specically designed for astronomical photography. It is not only suitable for
DSO imaging but also for Planetary imaging. You will be impressed by its superior performance
and wide use!
Models
Mono or Color
Regulated TEC Cooling
Sensor
ASI294MC
Color
No
SONY IMX294 CMOS
ASI294 MM
Mono
No
SONY IMX492 CMOS
ASI294MC Pro
Color
Yes
SONY IMX294 CMOS
ASI294MM Pro
Mono
Yes
SONY IMX492 CMOS
Which camera to choose?
Normally, mono camera sensors are with higher sensitivity, better at high-demand shooting tasks.
But extra accessories will be needed, such as filter wheel and lters, etc. Post processing of image
is also complicated, thus we recommend the color cameras to fresh users.
TEC cooling will help to reduce dark current noise for long exposures. For short exposures, such
as under one second, the dark current noise is very low. So cameras without TEC cooling are
normally recommend for planetary imaging. For DSO imaging, we recommend you use cooled
camera since long exposures are required.
For software installation instructions and other technical information, please refer to our ofcial
website https://astronomy-imaging-camera.com/
